Sharp LC-40LE510E Service Manual

111
LC-32LE510
LC-40LE510
REF No. PARTS DESCRIPTION *
PRICE
CODE
! C100 30067966 CAP MKP SAFE 220NF275VMACX215BOXLEFTBROH G --
! C101 30070590 CAPEL 47UF 450VM105C1200mA12.5X40SHALEFT G --
C102 30068025 CAP MKT SAFE 1UF 450V K 15DIPLB TOS RoHS G --
C103 30070590 CAPEL 47UF 450VM105C1200mA12.5X40SHALEFT G --
! C105 30067966 CAP MKP SAFE 220NF275VMACX215BOXLEFTBROH G --
! C109 30069935 CAP CER SAFE 1.5NF 4KV M 3.5MMSHARoHS G --
C112 30061026 CAP SMD 1UF 25V K X7R (0805) ROHS G --
! C113 30069936 CAP CER SAFE 150PF 4KV M 3.5MMSHAROHS G --
C114 30000294 CAP SMD 100NF 50V K X7R (0805) ROHS G --
!
C115 30068234 CAP MKP SAFE 100NF 275V M X2AC15BOX ROHS G --
C116 30066377 CAP CER 220PF 1KV K YRN 125C(PULSE) ROHS G --
C117 30000263 CAP SMD 56PF 50V J COG (0805) ROHS G --
! C118 30069936 CAP CER SAFE 150PF 4KV M 3.5MMSHAROHS G --
C120 30046152 CAP SMD 1UF 50V Z Y5V (0805) ROHS G --
C121 30069939 CAP CER SAFE 330PF 4KV M 3.5MMSHAROHS G --
! C122 30068025 CAP MKT SAFE 1UF 450V K 15DIPLB TOS RoHS G --
C123 30000284 CAP SMD 1NF 50V K X7R (0805) ROHS G --
C124 30046152 CAP SMD 1UF 50V Z Y5V (0805) ROHS G --
C129 30046152 CAP SMD 1UF 50V Z Y5V (0805) ROHS G --
C131 30046152 CAP SMD 1UF 50V Z Y5V (0805) ROHS G --
C133 30068234 CAP MKP SAFE 100NF 275V M X2AC15BOX ROHS G --
C134 30069935 CAP CER SAFE 1.5NF 4KV M 3.5MMSHARoHS G --
! C151 30069939 CAP CER SAFE 330PF 4KV M 3.5MMSHAROHS G --
C154 30046152 CAP SMD 1UF 50V Z Y5V (0805) ROHS G --
C155 30046152 CAP SMD 1UF 50V Z Y5V (0805) ROHS G --
C156 30046152 CAP SMD 1UF 50V Z Y5V (0805) ROHS G --
C181 30069939 CAP CER SAFE 330PF 4KV M 3.5MMSHAROHS G --
C190 30069935 CAP CER SAFE 1.5NF 4KV M 3.5MMSHARoHS G --
C191 30069939 CAP CER SAFE 330PF 4KV M 3.5MMSHAROHS G --
C193 30069936 CAP CER SAFE 150PF 4KV M 3.5MMSHAROHS G --
C195 30069935 CAP CER SAFE 1.5NF 4KV M 3.5MMSHARoHS G --
C198 30069936 CAP CER SAFE 150PF 4KV M 3.5MMSHAROHS G --
C200 30052271 CAP SMD 10UF 25V K X5R (1206) ROHS G --
C201 30000294 CAP SMD 100NF 50V K X7R (0805) ROHS G --
C207 30000309 CAP SMD 2.2NF 50V K X7R (0805) ROHS G --
C208 30070745 CAPEL 560UF 50V M105C 1500mA 8X40SHALEFT G --
C209 30070744 CAPEL 560UF 25V M105C1050mA 8X20SHALEFT G --
C210 30070745 CAPEL 560UF 50V M105C 1500mA 8X40SHALEFT G --
C211 30000294 CAP SMD 100NF 50V K X7R (0805) ROHS G --
C212 30070744 CAPEL 560UF 25V M105C1050mA 8X20SHALEFT G --
C213 30070849 CAP EL 47UF 50V M 105C 90mA 8x7SHARPROHS G --
C214 30068808 CAPMKPSAFE 15NF 630Vdc/622VppJ15LBENRoHS G --
C216 30000294 CAP SMD 100NF 50V K X7R (0805) ROHS G --
C217 30000309 CAP SMD 2.2NF 50V K X7R (0805) ROHS G --
C218 30070745 CAPEL 560UF 50V M105C 1500mA 8X40SHALEFT G --
C219 30061026 CAP SMD 1UF 25V K X7R (0805) ROHS G --
C220 30052271 CAP SMD 10UF 25V K X5R (1206) ROHS G --
C224 30070744 CAPEL 560UF 25V M105C1050mA 8X20SHALEFT G --
C228 30000265 CAP SMD 560PF 50V J COG (0805) ROHS G --
C230 30010561 CAP SMD 220NF 50V K X7R (0805) ROHS G --
C231 30000256 CAP SMD 470PF 50V J COG (0805) ROHS G --
C240 30070744 CAPEL 560UF 25V M105C1050mA 8X20SHALEFT G --
CAPACITORS
REF No. PARTS DESCRIPTION *
PRICE
CODE
C300 30070849 CAP EL 47UF 50V M 105C 90mA 8x7SHARPROHS G --
C302 30070849 CAP EL 47UF 50V M 105C 90mA 8x7SHARPROHS G --
C304 30000294 CAP SMD 100NF 50V K X7R (0805) ROHS G --
C307 30052271 CAP SMD 10UF 25V K X5R (1206) ROHS G --
C308 30070849 CAP EL 47UF 50V M 105C 90mA 8x7SHARPROHS G --
C309 30066237 CAP MKP 4.7NF 630Vdc/622Vpp K 7.5BOXROHS G --
C315 30070589 CAPEL 4.7UF 450VM 105C70mA10x12.5SHALEFT G --
C319 30067959 CAP EL 1000UF 16V M 105C 8x20LEFTBENDROH G --
C323 30070746 CAPEL 470UF 10V M105C 640mA 8X12 SHALEFT G --
C325 30070849 CAP EL 47UF 50V M 105C 90mA 8x7SHARPROHS G --
C326 30000294 CAP SMD 100NF 50V K X7R (0805) ROHS G --
C400 30000294 CAP SMD 100NF 50V K X7R (0805) ROHS G --
C401 30070746 CAPEL 470UF 10V M105C 640mA 8X12 SHALEFT G --
C402 30070746 CAPEL 470UF 10V M105C 640mA 8X12 SHALEFT G --
C403 30061026 CAP SMD 1UF 25V K X7R (0805) ROHS G --
C404 30015459 CAP SMD 470NF 25V K X7R (0805) RoHS G --
C405 30052271 CAP SMD 10UF 25V K X5R (1206) ROHS G --
C406 30052271 CAP SMD 10UF 25V K X5R (1206) ROHS G --
C407 30052271 CAP SMD 10UF 25V K X5R (1206) ROHS G --
C408 30000284 CAP SMD 1NF 50V K X7R (0805) ROHS G --
C411 30061026 CAP SMD 1UF 25V K X7R (0805) ROHS G --
C412 30000294 CAP SMD 100NF 50V K X7R (0805) ROHS G --
C413 30000284 CAP SMD 1NF 50V K X7R (0805) ROHS G --
C416 30052271 CAP SMD 10UF 25V K X5R (1206) ROHS G --
C418 30052271 CAP SMD 10UF 25V K X5R (1206) ROHS G --
C419 30000294 CAP SMD 100NF 50V K X7R (0805) ROHS G --
C420 30052271 CAP SMD 10UF 25V K X5R (1206) ROHS G --
C421 30000294 CAP SMD 100NF 50V K X7R (0805) ROHS G --
C422 30015459 CAP SMD 470NF 25V K X7R (0805) RoHS G --
C425 30000224 CAP SMD 220PF 50V J COG (0805) ROHS G --
C426 30000341 CAP SMD 68NF 50V K X7R (0805) ROHS G --
C427 30000341 CAP SMD 68NF 50V K X7R (0805) ROHS G --
C428 30000224 CAP SMD 220PF 50V J COG (0805) ROHS G --
C429 30061026 CAP SMD 1UF 25V K X7R (0805) ROHS G --
C430 30061026 CAP SMD 1UF 25V K X7R (0805) ROHS G --
C431 30052271 CAP SMD 10UF 25V K X5R (1206) ROHS G --
C434 30052271 CAP SMD 10UF 25V K X5R (1206) ROHS G --
! R100 30069236 CAP VAR SAFE 510V K JVR14N511K87I40 ROHS G --
R101 30007789 RES SMD 1/10W 27K F 0805 ROHS G --
R102 30000480 RES SMD 1/10W 100K J 0805 ROHS G --
R103 30050065 RES SMD 1/4W 619K F 1206 ROHS G --
R104 30050065 RES SMD 1/4W 619K F 1206 ROHS G --
R105 30050065 RES SMD 1/4W 619K F 1206 ROHS G --
R106 30000597 RES SMD 1/10W 22K J 0805 ROHS G --
R107 30000710 RES SMD 1/10W 47R J 0805 ROHS G --
R109 30006765 RES MO 2W 0.22R J TAPED RoHS G --
R110 30000480 RES SMD 1/10W 100K J 0805 ROHS G --
R112 30064313 RES SMD 1/10W 12K F (0805) ROHS G --
R116 30000475 RES SMD 1/10W 10K J 0805 ROHS G --
R120 30000571 RES SMD 1/10W 180K J 0805 ROHS G --
R125 30050064 RES SMD 1/4W 1.62M F 1206 ROHS G --
R126 30050064 RES SMD 1/4W 1.62M F 1206 ROHS G --
