LC-40/46LE814/824E/RU (1st Edition)

Service Manual

OUTLINE

MAJOR SERVICE PARTS

PWB UNIT

NOTE: (*1) Replace MAIN Unit (DKEYDF455FM11, DKEYDF455FM12) in case of IC8401 or IC3302 failure.

(*2) TOUCH SENSOR Unit (RUNTKA761WJQZ) reuse will be impossible, once it is stuck on front cabinet and

exfoliates.

Therefore, please exchange of a TOUCH SENSOR Unit in the case of front cabinet exchange.

OTHER UNIT

IC FOR EXCLUSIVE USE OF THE SERVICE

SERVICE JIGS

Ref No. Parts Code Description

N DKEYDF455FM11 MAIN Unit (LC-40LE814E/RU)(LC-46LE814E/RU) (*1)

N DKEYDF455FM12 MAIN Unit (LC-40LE824E/RU)(LC-46LE824E/RU) (*1)

N DUNTKF493FM03 ICON Unit

N DUNTKF493FM04 LOGO Unit (LC-40LE824E/RU)(LC-46LE824E/RU)

N DUNTKF494FM02 R/C, LED Unit

N RUNTKA685WJQZ POWER/LED CONTROL Unit (LC-40LE814E/RU)(LC-40LE824E/RU)

N RUNTKA686WJQZ POWER/LED CONTROL Unit (LC-46LE814E/RU)(LC-46LE824E/RU)

N RUNTKA692WJQZ TOUCH SENSOR Unit (LC-40LE814E/RU)(LC-46LE814E/RU)

N RUNTKA761WJQZ TOUCH SENSOR Unit (LC-40LE824E/RU)(LC-46LE824E/RU) (*2)

N RUNTK4512TPZC LCD CONTROL Unit

Ref No. Parts Code Description

N R1LK400D3LWF2Y 40" LCD Panel Module Unit (LC-40LE814E/RU)

N R1LK460D3LWG2Y 46" LCD Panel Module Unit (LC-46LE814E/RU)

N R1LK400D3LWF0Y 40" LCD Panel Module Unit (LC-40LE824E/RU)

N R1LK460D3LWG0Y 46" LCD Panel Module Unit (LC-46LE824E/RU)

Ref No. Parts Code Description Q’ty

IC501 RH-iXD108WJQZS IC (EDID for PC) 1

IC2002 RH-iXC786WJNJQ IC (Monitor MICON) 1

Ref No. Parts Code Description Q’ty

N QCNW-G616WJQZ Main Unit to LCD Control Unit (LW) 1

N QCNW-G625WJQZ Main Unit to Power Unit (PL) 1

N QCNW-H184WJQZ Main Unit to Power Unit (PD) 1

N QCNW-H185WJQZ Main Unit to Power Unit (LB) 1

N QCNW-K594WJQZ Main Unit to R/C, LED Unit (RA) 1

N QCNW-K595WJQZ Main Unit to Speaker (SP) 1

N QCNW-K596WJQZ Main Unit to Icon Unit (RL) (LC-40LE824E/RU)(LC-46LE824E/RU) 1

N QCNW-K597WJQZ Main Unit to Woofer (SB) 1
