LC-42/46/52D64U
26
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[10] CABINET AND MECHANICAL PARTS (LC-42D64U)
1 CCABAB823WJ31 BT N X Front Cabinet Ass'y
1-1 Not Available - N - Front Cabinet
1-2 XJPSN30P08XS0 AA J Screw (for Mask), x3
1-3 Not Available - N - Front Cover
1-4 Not Available - - Badge, SHARP
1-5 Not Available - - LED Decoration
1-6 HDECSA028WJ3A AM N X Shine Trim
1-7 HPNLSA147WJ3A AW N X Speaker Sheet
1-8 Not Available - N - Spacer, x6
1-9 Not Available - - Spacer, x2
1-10 Not Available - - Spacer
1-11 Not Available - - Spacer
1-12 Not Available - N - Spacer, x6
1-13 TLABZA635WJZZ AC J E-Star Label
2 CCABBB127WJ31 BX N X Rear Cabinet Ass'y
2-1 Not Available - N - Rear Cabinet
2-2 Not Available - - Terminal Label
3 CCOVAC392WJ31 AR N X Mini AV KEY Ass'y
3-1 Not Available - N - Mini AV KEY Cover
3-2 HINDPC516WJSA AF N X Mini AV Indicator
3-3 Not Available - N - Operation Button
4 R1LK420D3LZ50Z EZ N J 42" Wide LCD Panel Module Unit
5 CCHSMA386WJ31 BA X Tray Chassis Ass'y
5-1 Not Available - N - Tray Chassis
5-2 LHLDFA036WJKZ AC N X Wire Holder, x3
5-3 LHLDWA143WJKZ AC J Wire Holder, x6
5-4 LHLDWA151WJKZ AC N X Wire Holder, x5
5-5 LHLDWA172WJKZ AC N X Wire Holder
5-6 LHLDWA175WJUZ AC N X Wire Holder, x5
5-7 LHLDWA176WJUZ AC N X Wire Holder
6 HINDPC478WJSA AH N X Model Label
7 HINDPC479WJSA AE N X Terminal Label
8 LANGKB187WJ3W AX X Panel Support Angle, x2
9 LANGKB194WJFW AG N X
Terminal Side Angle
10 LANGKB195WJFW AH X Terminal Bottom Angle
11 LANGKB216WJ3W AG N X Mini AV Angle
12 LANGKB240WJFW AK N X Radiator Angle
13 LHLDWA133WJKZ AC N J Wire Holder
14 LHLDWA143WJKZ AC N J Wire Holder, x2
15 LHLDWA151WJKZ AC N X Wire Holder
16 LHLDWA164WJKZ AD N J Wire Holder
17 LHLDWA175WJUZ AC N X Wire Holder, x2
18 LHLDWA176WJUZ AC N X Wire Holder, x4
19 GCOVAC336WJ3A BB N X Bottom Cover
20 PZETKA273WJZZ AC N X Barrier Sheet
21 NSFTZ0134CEFW AD J Shaft, x4
22 PCOVP2609TPZZ AH N X LCD Control Shield
23 PRDARA485WJFW AW N X Heat Sink
24 CSLDMB158WJ31 AL N X MAIN Shield Ass'y
24-1 Not Available - N - MAIN Shield
24-2 PSPAZB622WJZZ AB N X Spacer
25 PSLDMB159WJ3W AK X AV Shield
26 PSLDMB179WJ3W AD X Mini AV Shield
27 PSPAZB596WJKZ AN N X Spacer, x3
28 PSPAZB597WJKZ AG N X Spacer, x2
29 QCNCMA275WJQZ AC N X Connector, x2
30 QCNCMA673WJZZ AG J Connector
31 QCNW-F922WJQZ AF N X Connecting Cord (AC)
32 QCNW-F923WJQZ AF N X Connecting Cord (PE)
33 QCNW-F924WJQZ AG N X Connecting Cord (PD)
34 QCNW-G161WJQZ AG N X Connecting Cord (LB)
35 QCNW-G163WJQZ AG N X Connecting Cord (LA1)
36 QCNW-G164WJQZ AG N X Connecting Cord (KM)
37 QCNW-G165WJQZ AM N X Connecting Cord (LP)
38 QCNW-G166WJPZ AK N X Connecting Cord (US)
39 QCNW-G167WJQZ AU N X Connecting Cord (VD)
40 QCNW-G168WJQZ AK N X Connecting Cord (RA)
41
QCNW-G169WJQZ AH N X Connecting Cord (SP)
42 QCNW-G170WJQZ AF N X Connecting Cord (PL)
43 QPWBHE321WJQZ AX N J Connecting Cord (HM)
44 QPWBHE337WJQZ BA N X Connecting Cord (LW)
45 RSP-ZA261WJZZ AZ N X Speaker (L)
46 RSP-ZA262WJZZ AZ N X Speaker (R)
47 TLABK0023TAZZ AA J Label
48 Not Available - - No. Label
49 XBBS740P06000 AA J Screw (for Support), x14
50 XBPS730P06WS0 AA J Screw (for PWB), x22 (for Tray), x27
51 XBPS830P06000 AA J Screw (for HDMI), x2
52 XBPS930P08WS0 AA X Screw (for MINI-AV PWB), x2
53 XBPS940P10JS0 AB J Screw, x7
54 XEBS930P10000 AA J Screw (for Bottom Cover)
55 XEBS940P16000 AB J Screw (for CAB), x15
56 XIPSN20P04000 AA J Screw (for MINI HDMI), x2
57 PSPAKA237WJ00 AA X Spacer, x5
58 CDAI-A418WJ32 BQ N X Stand Ass'y
