LC-42/46/52D64U
27
NO.
P
ARTS CODE
PRICE
RANK
NEW
MARK
PA
R
T
DELIVERY
DESCRIPTION
58-1
CDAI
-A418WJ31
AE
N
X
Stand Base Ass'y
58-2
CDAI
-A419WJ31
AD
N
X
Stand Support Ass'y
58-3
Not Av
ailable
-
-
Screw (for Stand), x4
58-4
Not Av
ailable
-
N
-
Screw (for Stand), x4
59
XBSS
740P08000
AB
N
X
Screw
[10] CABINET AND MECHANICAL PART
S (LC-42D64U)
158
160
Table of Contents
Default Chapter
1
Table of Contents
1
Service Manual
1
Safety Precaution Important Service Safety Precaution
2
Precautions a Prendre Lors de la Reparation
3
Precautions for Using Lead-Free Solder
4
Chapter 1. Specifications Specifications
5
Operation Manual
6
Part Names
6
Chapter 2. Operation Manual
6
Remote Control Unit
7
Removing the Stand
8
Setting the TV on the Wall
8
Troubleshooting
9
Troubleshooting-Digital Broadcasting
9
Preparation
10
PC Compatibility Chart
10
Basic Adjustment Settings
11
Menu Items for TV/INPUT 1/2/3
11
Menu Items for HDMI/PC-IN
11
Chapter 3. Dimensions
12
Dimensions (Lc-42D64U)
12
Dimensions (Lc-46D64U)
13
Dimensions (Lc-52D64U)
14
Chapter 4. Removing of Major Parts Removing of Major Parts (Lc-42D64U)
15
Removing of Major Parts (Lc-46/52D64U)
15
Remove the Speaker-L and R
18
Removing of Major Parts (LC-46/52D64U)
21
Adjustment Procedure
27
Upgrading of each Microprocessor Software
27
Main Software Version Upgrade
27
Monitor Microprocessor Software Version Upgrade
29
How to Upgrade the Software
29
Entering and Exiting the Adjustment Process Mode
30
Remote Controller Key Operation
30
Description of Display in Adjustment Process Mode
30
List of Adjustment Process Mode Menu
31
Special Features
36
Video Signal Adjustment Procedure
36
Signal Check
36
Entering the Adjustment Process Mode
36
N358 Composite Signal Adjustment (Tuner)
37
Component 15K Signal Adjustment
37
Component 33K Signal Adjustment
37
Analog RGB Signal Adjustment
37
Chapter 5 . Adjustment
37
Adjustment Procedure
37
Tuner/V-Chip Test
38
Adjustment of White Balance
39
Adjusting Procedure by Use of RS-232C
40
Model Number ID Plug
41
Chapter 6. Trouble Shooting Table
43
Trouble Shooting Table
43
Major IC Informations
64
Chapter 7. Major IC Informations
64
Chapter 8. Overall Wiring/Block Diagram Overall Wiring Diagram (Lc-42D64U)
66
Overall Wiring Diagram (Lc-46/52D64U)
68
System Block Diagram
70
CHAPTER 9. PRINTED WIRING BOARD ASSEMBLIES MAIN Unit
72
Terminal Unit
80
Side Unit
82
R/C, LED Unit
84
Key Unit
85
Description of Schematic Diagram
86
Voltage Measurement Condition
86
Indication of Resistor and Capacitor
86
Chapter 10. Schematic Diagram
86
R/C, LED Unit
87
MAIN Unit
88
TERMINAL Unit
122
SIDE Unit
128
KEY Unit
132
Parts Guide Contents
133
LCD Panel
134
Duntke207Fm01
134
Dunkte208Fm01
150
Conductive Cloth Tape
155
Added Parts
155
Temperature-Proof Cover
156
Cabinet and Mechanical Parts
157
Supplied Accessories
165
Packing Parts
166
Service Jig
171
