No sound from external input devices (1)
Does not the sound of the audio signal input to input (Component) go out?
MAIN UNIT:
YES
NO
Is the audio signal properly sent to pin (8) and pin (10) of
CN1202?
NO
Check the connection to CN1202 and the external input device.
Is the audio signal properly sent to pin (68)
(AIN0_R) and pin (70) (AIN0_L) of IC
U2102?
Check the line between CN1202 and IC U2102.
YES
Refer to “No sound output in all modes”.
