Sharp LC-42XL2S User Manual

LC-42XL2E/S/RU, LC-46XL2E/S/RU, LC-46X20E/S/RU, LC-52XL2E/S/RU, LC-52X20E/S/RU
2 – 29
Wire "LC", "LA1" to WH
Wire "LC" to WH
Wire "LW" to WH
Wire "LW" to WH
#For EMC
Set Wire "LW" under other wires
Wire "FR" to WH
Wire "LC","PL","FR" to WH
Wire "LC","FR" to WH
Wire "KM"
Wire "LW"
Wire "PL"
Wire "FR"
Wire "LA1"
Wire "LB"
Wire "LA2"
Wire "VD"
FFC "HM"
Wire "US"
for Wire "KM"
#Wind Wire "KM" one time to core
Set taping to core inside.
To Main PWB
To Key PWB
Wind wire "KM" one
time to core.
#For EMC,Set Wire "LW" under other wires.
