Sharp LC-42XL2S User Manual

LC-42XL2E/S/RU, LC-46XL2E/S/RU, LC-46X20E/S/RU, LC-52XL2E/S/RU, LC-52X20E/S/RU
2 – 30
6. Remove the R/C, LED Unit.
7. Remove the 4 lock screws . and detach the CTL SHIELD.
R/C, LED PWB
Wire "RA"
from OBON
Wire "RA"
R/C, LED PWBFront side
LED PWB Back side
Pull out Wire "RA" from bottom
1st,Set R/C, LED PWB Under LIB
R/C, LED PWB
(with wire)
Next,Push PWB hooked
#Set PWB to gide lib surely
Wire "RA" to WH
Set Wire "RA" to
panel hollow.
7
7
