LC-42XL2E/S/RU, LC-46XL2E/S/RU, LC-46X20E/S/RU, LC-52XL2E/S/RU, LC-52X20E/S/RU
2 – 46
14.Remove all the connectors from PWBs.
15.Remove the 8 lock screws , and the 2 lock screws . Detach the Main Shield and AV Shield.
15
16
Open Side
Wire "LV" to WH
15
16
AV SHIELD
MAIN SHIELD
Wire "LW"
Pull out Wire "LW" form Opening
