8
Cup hook (commercially available)
Wall
Clamps
(supplied)
Affi x the TV to the wall or a
pillar using extra strong ties
and cup hooks.
Affi x the 2 clamps (supplied)
to the product using the
screws (supplied).
1
2
Tie (commercially available)
Screws for attaching clamps (supplied)
View from the top
Protection against overturning
There is a danger of the product overturning in the case of a disaster or sudden collision. Carry out the following
tip-resistant measurement for your safety.
Anchoring the TV to the wall or a pillar
Preparation
Insert commercially available screws in the
holes of the restraining brackets from the top
and tighten the screws to secure the TV to the
table.
• Use commercially available screws of the proper
size to fi rmly secure the TV.
3
Fixing the TV to the table (For LC-60LX710H only)
Attach the two supplied restraining brackets to
the stand with four supplied screws.
Place the TV on the table.
1
2
CAUTION
• As this product is heavy, use a table that is wide
enough to support the product and capable of
withstanding the product's weight. The table should
be set where it will not be overturned.
• Be sure to use at least two people when moving the TV.
Stand
Restraining brackets
(supplied)
Screws
(Supplied)
Screws (Commercially
available)
Restraining brackets (supplied)
40LX710H_en.indd 840LX710H_en.indd 8 2010/04/15 16:11:082010/04/15 16:11:08
