2.8. IC1507 (VHiSii9185+-1Q)
2.8.1 Block Diagram
57 LIN4 I Lch Input 4
58 RIN4 I Rch Input 4
59 LIN5 I Lch Input 5
60 RIN5 I Rch Input 5
61 LIN6 I Lch Input 6
62 RIN6 I Rch Input 6
63 PVSS — PLL Ground
64 R — External Resistor
Pin No. Pin Name I/O Pin Function
