LC-42XL2E/S/RU, LC-46XL2E/S/RU, LC-46X20E/S/RU, LC-52XL2E/S/RU, LC-52X20E/S/RU
5 – 27
D12 POD_CE1 O Card enable.
E12 POD_CTX O POD OOB TX Gapped Symbol clock.
A11 POD_DRX O POD OOB RX data.
B11 POD_CD1 I Card Detect.
C11 POD_IREQ I Ready/IRQ
D11 POD_CRX O POD OOB RX Gapped clock.
E11 POD_RESET O POD Card reset signal.
A10 POD_QTX I POD OOB TX Q Channel.
B10 POD_VS1 I Card voltage Sense.
C10 POD_ETX I POD OOB TX enable.
D10 POD_CD2 I Card Detect.
E10 POD_CE2 O Card enable.
A9 POD_VPP_EN O Slot VPP enable.
B9 POD_OVERLOAD I Current overload detect.
C9 POD_VPP_EN# O Slot VPP enable.
D9 POD_VCC_EN# O Slot VCC enable.
E9 POD_VCC_EN O Slot VCC enable.
A8 POD_A9 O POD Host interface address bit 9.
B8 POD_A8 O POD Host interface address bit 8.
C8 POD_A7 I/O POD Host interface address bit 7.
D8 POD_A6 I/O POD Host interface address bit 6.
D7 POD_A5 I/O POD Host interface address bit 5.
C7 POD_A4 O POD Host interface address bit 4.
VDA Interface
AP13, AN13, AM13, AL13,
AK13, AP14, AN14, AM14,
AL14, AK14
VDA_R[9:0] I Video input, R channel. (Not used)
AP15, AN15, AM15, AL15,
AK15, AM16, AL16, AK16,
AP17, AN17
VDA_B[9:0] I Video input, B channel. (Not used)
AM17, AL17, AK17, AP18,
AN18, AM18, AL18, AK18,
AP19, AN19
VDA_G[9:0] I Video input, G channel. (Not used)
AP16 VDA_CLK I Video input, Clock. (Not used)
AM19 VDA_VS I Video input, Vertical sync. (Not used)
AL19 VDA_HS I Video input, Horizontal sync. (Not used)
AK19 VDA_DE I Video input, Data enable. (Not used)
VDB Interface, EJTAG, IDE and POD2 share with VDB
AK20 VDB_DE I/O Video input/output; data enable;
IDE: IDE bus interrupt.
EJTAG: NOP
POD2: POD_CE2B#, the second POD Card enable.
AL20 VDB_HS I/O Video input/output; Horizontal sync;
IDE: PDLAGCBLID, Passed diagnostics, cable assembly type identifier.
EJTAG: TDI2, TDI EJTAG input of slave CPU.
POD2: POD_A_B5, the second POD host interface address bit 5.
AM20 VDB_VS I/O Video input/output; Vertical sync;
IDE: DMAREQ, IDE bus DMA request.
EJTAG: NOP
POD2: POD_A_B4, the second POD host interface address bit 4.
AN20 VDB_G0 I/O Video input/output; Green channel bit 0;
IDE: IDE data bus bit 0.
EJTAG: TDO2, TDO EJTAG input of slave CPU CPU.
POD2: POD_A_B6, the second POD host interface address bit 6.
AP20 VDB_G1 I/O Video input/output; Green channel bit 1;
IDE: IDE data bus bit 1.
EJTAG: TMS2, TMS EJTAG input of slave CPU CPU.
POD2: POD_A_B7, the second POD host interface address bit 7.
AK21 VDB_G2 I/O Video input/output; Green channel bit 2;
IDE: IDE data bus bit 2.
EJTAG: TCK2, TCK EJTAG input of slave CPU CPU.
POD2: POD_A_B8, the second POD host interface address bit 8.
AL21 VDB_G3 I/O Video input/output; Green channel bit 3;
IDE: IDE data bus bit 3.
EJTAG: DCLK EJTAG output of both CPU CPUs.
POD2: POD_A_B8, the second POD host interface address bit 9.
Ref No. Pin Name I/O Pin Function
