LC-42XL2E/S/RU, LC-46XL2E/S/RU, LC-46X20E/S/RU, LC-52XL2E/S/RU, LC-52X20E/S/RU
2 – 60
16.Remove the 8 lock screws , and the 2 lock screws . Detach the Main Shield and AV Shield.
17 18
Wire "LW" to WH
Wire "LW"
17
18
AV SHIELD
MAIN SHIELD
Wire "LW"
Pull out Wire "LW" form Opening
