LC-52/60LE830E,RU/831E,S/833E
iv
LC52LE830E
Service Manual
OUTLINE
MAJOR SERVICE PARTS
PWB Unit
NOTE: (*1) Replace MAIN Unit (DKEYDF733FM**) in case of IC8401 or IC3303 failure.
(*2) TOUCH SENSOR Unit (RUNTKA869WJQZ) reuse will be impossible, once it is stuck on front cabinet and exfoliates.
OTHER Unit
IC For Exclusive Use Of The Service
Service Jigs
Ref No. Parts No. Description
N DKEYDF733FM51 MAIN Unit (LC-52/60LE830E,RU)
N DKEYDF733FM52 MAIN Unit (LC-52/60LE831E,S)
N DKEYDF733FM54 MAIN Unit (LC-52/60LE833E)
N DUNTKF494FM02 R/C OPERATION Unit
N DUNTKF770FM51 ICON Unit
N RUNTKA869WJQZ TOUCH SENSOR Unit
N RUNTKA819WJQZ 3D IR TRANSMITTER Unit
N RUNTKA795WJQZ POWER SUPPLY Unit (LC-52LE830E,RU/831E,S/833E)
N RUNTKA799WJN1 POWER SUPPLY Unit (LC-60LE830E,RU/831E,S/833E)
N RUNTK4909TPYX LCD CONTROL Unit (LC-52LE830E,RU/831E,S/833E)
N RUNTK4909TPYN LCD CONTROL Unit (LC-60LE830E,RU/831E,S/833E)
Ref No. Parts No. Description
N R1LK520D3GW4BY 52" LCD Panel Module Unit (LK520D3GW4BY) (LC-52LE830E,RU/831E,S/833E)
N R1LK600D3GW4BH 60" LCD Panel Module Unit (LK600D3GW4BH) (LC-60LE830E,RU/831E,S/833E)
Ref No. Parts No. Description Q'ty
IC2001 RH-iXD241WJN2Q IC R5F21368CNFP (Monitor Microcomputer) 1
Ref No. Parts No. Description Q'ty
N QCNW-L795WJQZ Main Unit to Power Unit (PD) 1
N QCNW-L798WJQZ Main Unit to Touch Sensor/IR Transmitter Units (RC) 1
N QCNW-L796WJQZ Main Unit to ICON Unit (CI) 1
N QCNW-K595WJQZ Main Unit to Speaker (SP) 1
N QCNW-G405WJQZ Main Unit to LCD Control Unit (PL) 1
N QCNW-F676WJQZ Power Unit to LCD Control Unit (LW) 1
N QCNW-K597WJQZ Main Unit to Woofer (SB) 1
