LC-46D82U/LC-52D82U
2 – 5
11.Remove all the connectors from PWBs.
12.Remove the 1 lock screw , and detach the LED Unit.
LB
L
Connect Wire(L)
LA
LC
LA
LC
LB
L
㪣㪙
WH
10
LA
LC
LA
LC
㵘ILLUMINATIN UNIT
RA
㵘 LED UNIT
LED UNIT
RA
SP
LA
LB
RA
RA
HANG
HANG
Connect Wire(RA)
TERMINAL-ILLUMINATION
LB
RIB-CAB
*CAUTION
"RA" wire should pass on the right of CAB-RIV.
HANG
INSERT
ShapeRAx3
For RIB-CAB
Connect Wire(RA)
TERMINAL䋭LED
10
