PARTS GUIDE
Parts marked with " " are important for maintaining the safety of the set. Be sure to replace these
parts with specified ones for maintaining the safety and performance of the set.
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.
LC-46D82U/LC-52D82U
PartsGuide
[1] PRINTED WIRING BOARD
ASSEMBLIES
(NOT REPLACEMENT ITEM)
[2] LCD PANEL AND TUNER
(NOTE: THE PARTS HERE
SHOWN ARE SUPPLIED AS AN
ASSEMBLY BUT NOT
INDEPENDENTLY.)
[3] DUNTKE028FE03 (MAIN Unit)
[4] DUNTKD935FE10 (TERMINAL Unit)
[5] DUNTKD910FE02 (KEY Unit)
[6] DUNTKD909FE02 (R/C, LED Unit)
[7] DUNTKD888WE01
(ILLUMINATION Unit)
[8] DUNTKE046FE02 (FRC Unit)
[9] CABINET PARTS (LC-46D82U)
[10] CABINET PARTS (LC-52D82U)
[11] SUPPLIED ACCESSORIES
[12] PACKING PARTS
(NOT REPLACEMENT ITEM)
[13] SERVICE JIGS
(USE FOR SERVICING)
CONTENTS
LCD COLOR TELEVISION
LC-52D82U
LC-46D82U
MODELS
