LC-46D82U/LC-52D82U
2
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
[1] PRINTED WIRING BOARD ASSEMBLIES (NOT REPLACEMENT ITEM)
N DUNTKE028FM03 N R MAIN Unit
N DUNTKD935FM10 BG N X TERMINAL Unit
N DUNTKD910FM02 AG N X KEY Unit
N DUNTKD909FM02 AQ N X R/C, LED Unit
N DUNTKD888FM01 AH N X ILLUMINATION Unit
N DUNTKE046FE02 CC N J FRC Unit
N RDENCA205WJQZ BU X POWER SUPPLY Unit (Unit exchange)
[2] LCD PANEL AND TUNER (NOTE: THE PARTS HERE SHOWN ARE SUPPLIED AS AN ASSEMBLY BUT
NOT INDEPENDENTLY.)
N R1LK460D3LZ2CZ GG N J 46" LCD Panel Module
N R1LK520D3LZ2CZ HC N J 52" LCD Panel Module
TU1101 RTUDAA007WJQZ BB R Tuner
[3] DUNTKE028FE03 (MAIN Unit)
C1101 VCKYCZ1EF104ZY AA R Capacitor 0.1 25V Ceramic
C1102 RC-KZA510WJPZY AB R Capacitor 10 16V Ceramic
C1103 VCKYCZ1EB103KY AA R Capacitor 0.01 25V Ceramic
C1104 RC-KZA510WJPZY AB R Capacitor 10 16V Ceramic
C1105 VCKYCZ1EB103KY AA R Capacitor 0.01 25V Ceramic
C1107 RC-KZA114WJZZY AB R Capacitor 1 25V Ceramic
C1108 VCKYCZ1EF104ZY AA R Capacitor 0.1 25V Ceramic
C1110 RC-KZA030WJZZY AB R Capacitor 2.2 10V Ceramic
C1111 RC-KZA030WJZZY AB R Capacitor 2.2 10V Ceramic
C1112 VCKYCZ1EB103KY AA R Capacitor 0.01 25V Ceramic
C1113 VCKYCZ1EB103KY AA R Capacitor 0.01 25V Ceramic
C1115 VCKYCZ1EF104ZY AA R Capacitor 0.1 25V Ceramic
C1116 VCKYCZ1EF104ZY AA R Capacitor 0.1 25V Ceramic
C1118 RC-KZA510WJPZY AB R Capacitor 10 16V Ceramic
C1120 VCKYCZ1EB103KY AA R Capacitor 0.01 25V Ceramic
C1122 VCERML1CN476MY AC R Capacitor 47 16V Capacitor(AL)
C1123 VCKYCZ1EB103KY AA R Capacitor 0.01 25V Ceramic
C1127 VCKYCZ1HB102KY AB R Capacitor 1000p 50V Ceramic
C1133 VCKYCZ1HB102KY AB R Capacitor 1000p 50V Ceramic
C1134 VCKYCZ1HB102KY AB R Capacitor 1000p 50V Ceramic
C1301 VCKYCZ1EF104ZY AA R Capacitor 0.1 25V Ceramic
C1303 RC-KZA510WJPZY AB R Capacitor 10 16V Ceramic
C1305 VCKYCZ1EF104ZY AA R Capacitor 0.1 25V Ceramic
C1308 VCKYCZ1EF104ZY AA R Capacitor 0.1 25V Ceramic
C1309 RC-KZA383WJZZY AC R Capacitor 10 25V Ceramic
C1313 RC-KZA510WJPZY AB R Capacitor 10 16V Ceramic
C1314 VCKYCZ1EF104ZY AA R Capacitor 0.1 25V Ceramic
C1315 RC-KZA510WJPZY AB R Capacitor 10 16V Ceramic
C1316 VCKYCZ1EF104ZY AA R Capacitor 0.1 25V Ceramic
C1401 RC-KZA030WJZZY AB R Capacitor 2.2 10V Ceramic
C1402 VCKYCZ1EF104ZY AA R Capacitor 0.1 25V Ceramic
C1403 VCKYCZ1AB104KY AB R Capacitor 0.1 10V Ceramic
C1404 VCKYCY1AB334KY AB R Capacitor 0.33 10V Ceramic
C1405 VCKYCZ1EF104ZY AA R
Capacitor 0.1 25V Ceramic
C1406 VCERMZ1CN107MY AD R Capacitor 100 16V Capacitor(AL)
C1407 RC-KZA030WJZZY AB R Capacitor 2.2 10V Ceramic
C1408 VCKYCZ1AB104KY AB R Capacitor 0.1 10V Ceramic
C1409 VCKYCZ1CB223KY AC R Capacitor 0.022 16V Ceramic
C1410 RC-KZA383WJZZY AC R Capacitor 10 25V Ceramic
C1411 RC-KZA508WJQZY AC R Capacitor 3.3 25V Ceramic
C1412 RC-KZA030WJZZY AB R Capacitor 2.2 10V Ceramic
C1414 RC-KZA069WJZZY AB R Capacitor 4.7 10V Ceramic
C1416 VCKYCZ1HB102KY AB R Capacitor 1000p 50V Ceramic
C1417 VCKYCZ1AB104KY AB R Capacitor 0.1 10V Ceramic
C1418 VCKYCZ1CB333KY AA R Capacitor 0.033 16V Ceramic
C1419 VCKYCY1CB224KY AB R Capacitor 0.22 16V Ceramic
C1420 VCKYCZ1AB104KY AB R Capacitor 0.1 10V Ceramic
C1421 RC-KZA030WJZZY AB R Capacitor 2.2 10V Ceramic
C1422 VCKYCY1AB334KY AB R Capacitor 0.33 10V Ceramic
C1423 VCKYCZ1EF104ZY AA R Capacitor 0.1 25V Ceramic
C1424 VCERML1CN476MY AC R Capacitor 47 16V Capacitor(AL)
C1425 VCKYCZ1EF104ZY AA R Capacitor 0.1 25V Ceramic
C1426 RC-KZA510WJPZY AB R Capacitor 10 16V Ceramic
C1428 VCCCCZ1HH330JY AB R Capacitor 33p 50V Ceramic
C1429 VCCCCZ1HH330JY AB R Capacitor 33p 50V Ceramic
C1430 VCKYCZ1EF104ZY AA R Capacitor 0.1 25V Ceramic
C1433 RC-KZA069WJZZY AB R Capacitor 4.7 10V Ceramic
C1434 VCKYCZ1EF104ZY AA R Capacitor 0.1 25V Ceramic
C1435 VCKYCZ1EF104ZY AA R Capacitor 0.1 25V Ceramic
C1436 VCKYCZ1EF104ZY AA R Capacitor 0.1 25V Ceramic
C1437 RC-KZA510WJPZY AB R Capacitor 10 16V Ceramic
C1438 VCKYCZ1EF104ZY AA R Capacitor 0.1 25V Ceramic
C1439 RC-KZA176WJZZY AC R Capacitor 10 10V Ceramic
C1440 RC-KZA030WJZZY AB R Capacitor 2.2 10V Ceramic
C1441 VCKYTV1CB105KY AC R Capacitor 1 16V Ceramic
C1443 VCKYTV1CB105KY AC R Capacitor 1 16V Ceramic
C1444 VCKYTV1CB105KY AC R Capacitor 1 16V Ceramic
C1447
VCKYTV1CB105KY AC R Capacitor 1 16V Ceramic
C1449 VCKYTV1CB105KY AC R Capacitor 1 16V Ceramic
