LC-46D82U/LC-52D82U
2 – 13
4. Remove the 8 lock screws and detach the Stand Set Cover.
5. Remove the 8 lock screws and detach the Stand Fix Angle.
4
STAND ST COV-R
INSERT
LOCK
INSERT
LOCK
4 4
5
STAND FIX ANG
5
