LC-46D82U/LC-52D82U
4 – 4
[COMPOSITE signal input] Is there the COMPONENT video signal input at pins (U3) (Y) / (AA1) (Pb) and (W3)
(Pr) of IC3301 (VPC)?
NO
Check the line
between
SC1101 nad
IC3301 and its
periphen cir-
cuits.
[S-VIDEO signal input] Is there the video signal input at pins (M4, N4)(Y) and (T1)(C) of IC3301 (VPC)?
NO
Check the line
between SC1101
and IC3301 (Q2201
thru Q2203,
Q2205, Q2207.
Q2209, etc.).
YES
Is there the LVDS signal output at the LVDS 1st channel and 2nd channel of IC3301?
TA2_P/M(AJ30/AK30), TB2_P/M(AJ29/AK29), TC2_P/M(AJ28/AK28), TD2_P/M(AJ26/AK26), TE2_P/M(AJ25/
AK25), TCLK2_P/M(AJ27/AK27), TA1_P/M(AB29/AB30), TB1_P/M(AC29/AC30), TC1_P/M(AD29/AD30),
TD1_P/M(AF29/AF30), TE1_P/M(AG29/AG30), TCLK1_P/M(AE29/AE30)
Check IC3301 and
its peripheral con-
trol circuits
(IC3501, IC3502,
IC8101, etc.).
NO
YES
Check the panel module.
