Sharp LC-52LE700E Service Manual

LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S
12
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R1531 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R1536 VRK-SA1JF100JY AB J Resistor 10 1/16W Metal Composition
R1537 VRK-SA1JF100JY AB J Resistor 10 1/16W Metal Composition
R1539 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R1541 VRK-SA1JF100JY AB J Resistor 10 1/16W Metal Composition
R1542 VRS-CZ1JF332JY AA J Resistor 3.3k 1/16W Metal Oxide
R1543 VRK-SA1JF100JY AB J Resistor 10 1/16W Metal Composition
R1551 VRS-CZ1JF332JY AA J Resistor 3.3k 1/16W Metal Oxide
R1552 VRS-CZ1JF100JY AA J Resistor 10 1/16W Metal Oxide
R1553 VRS-CZ1JF332JY AA J Resistor 3.3k 1/16W Metal Oxide
R1554 VRS-CZ1JF332JY AA J Resistor 3.3k 1/16W Metal Oxide
R1555 VRS-CZ1JF100JY AA J Resistor 10 1/16W Metal Oxide
R1556 VRS-CZ1JF100JY AA J Resistor 10 1/16W Metal Oxide
R1557 VRS-CZ1JF100JY AA J Resistor 10 1/16W Metal Oxide
R1558 VRS-CZ1JF331JY AA J Resistor 330 1/16W Metal Oxide
R1559 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R1561 VRK-SA1JF473JY AC J Resistor 47k 1/16W Metal Composition
R1564 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R1565 VRK-SA1JF473JY AC J Resistor 47k 1/16W Metal Composition
R1582 VRK-SA1JF100JY AB J Resistor 10 1/16W Metal Composition
R1584 VRS-CZ1JF100JY AA J Resistor 10 1/16W Metal Oxide
R2001 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R2002 VRS-CZ1JF104JY AA J Resistor 100k 1/16W Metal Oxide
R2003 VRS-CZ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R2004 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R2005 VRS-CZ1JF100JY AA J Resistor 10 1/16W Metal Oxide
R2007 VRS-CZ1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
R2008 VRS-CZ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R2009 VRS-CZ1JF102JY AA J Resistor 1k 1/16W Metal Oxide
R2010 VRS-CZ1JF333JY AA J Resistor 33k 1/16W Metal Oxide
R2011 VRS-CZ1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
R2012 VRK-SB1FF103JY AA J Resistor 10k 1/32W Metal Composition
R2014 VRS-CZ1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
R2015 VRK-SA1JF100JY AB J
Resistor 10 1/16W Metal Composition
R2016 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R2017 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R2018 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R2019 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R2020 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R2021 VRS-CZ1JF104JY AA J Resistor 100k 1/16W Metal Oxide
R2022 VRS-CZ1JF333JY AA J Resistor 33k 1/16W Metal Oxide
R2023 VRS-CZ1JF473FY AA J Resistor 47k 1/16W Metal Oxide
R2024 VRS-CZ1JF102FY AA J Resistor 1k 1/16W Metal Oxide
R2025 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R2026 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R2028 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R2029 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R2030 VRS-CZ1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
R2031 VRK-SA1JF103JY AB J Resistor 10k 1/16W Metal Composition
R2032 VRS-CZ1JF223JY AA J Resistor 22k 1/16W Metal Oxide
R2033 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R2034 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R2035 VRS-CZ1JF333JY AA J Resistor 33k 1/16W Metal Oxide
R2036 VRS-CZ1JF105JY AA J Resistor 1M 1/16W Metal Oxide
R2038 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R2039 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R2040 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R2041 VRS-CZ1JF152JY AA J Resistor 1.5k 1/16W Metal Oxide
R2042 VRS-CG1JF101JY AA J Resistor 100 1/16W Metal Oxide
R2044 VRS-CZ1JF100JY AA J Resistor 10 1/16W Metal Oxide
R2045 VRS-CY1JF106JY AA J Resistor 10M 1/16W Metal Oxide
R2047 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R2048 VRS-CZ1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
R2049 VRS-CZ1JF272FY AA J Resistor 2.7k 1/16W Metal Oxide
R2050 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R2051 VRK-SA1JF100JY AB J Resistor 10 1/16W Metal Composition
R2052 VRS-CZ1JF223JY AA J Resistor 22k 1/16W Metal Oxide
R2053
VRS-CY1JF394FY AA J Resistor 390k 1/16W Metal Oxide
R2054 VRS-CZ1JF223JY AA J Resistor 22k 1/16W Metal Oxide
R2056 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R2057 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R2058 VRS-CZ1JF100JY AA J Resistor 10 1/16W Metal Oxide
R2061 VRS-CZ1JF223JY AA J Resistor 22k 1/16W Metal Oxide
R2064 VRS-CZ1JF100JY AA J Resistor 10 1/16W Metal Oxide
R2066 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R2068 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R2070 VRS-CZ1JF100JY AA J Resistor 10 1/16W Metal Oxide
R2071 VRS-CZ1JF100JY AA J Resistor 10 1/16W Metal Oxide
R2072 VRS-CZ1JF104JY AA J Resistor 100k 1/16W Metal Oxide
R2075 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R2076 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R2077 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R2078 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R2079 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R2085 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
[3] DUNTKE306FM01 (MAIN Unit)

Sharp LC-52LE700E Specifications

General

Display diagonal	52 \
Display brightness	450 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Viewable size diagonal	1320 mm
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	4000:1
Viewing angle, horizontal	176 °
Power requirements	AC 220-240 V / 50 Hz
RS-232 ports	1
HDMI ports quantity	4
SCART ports quantity	2
Component video (YPbPr/YCbCr) in	3
Product color	Black
Tuner type	Analog & digital
Analog signal format system	NTSC

Weight and Dimensions

Depth (without stand)	95 mm
Width (without stand)	1238 mm
Height (without stand)	765 mm
Weight (without stand)	27600 g
