Sharp LC-52LE700E Service Manual

LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S
1 – 1
LC32LE700E
ServiceManual

CHAPTER 1. SPECIFICATIONS
[1] SPECIFICATIONS
1. LC-32LE700E/RU/S, LU700E/S, LX700E/RU, LC-40LE700E/RU/S, LU700E/S, LX700E/RU
Item
LCD COLOUR TV (32"), LC-32LE700E,
LC-32LE700RU, LC-32LE700S, LC-32LX
700E, LC-32LX700RU, LC-32LU700E,
LC-32LU700S
LCD COLOUR TV (40"), LC-40LE700E,
LC-40LE700RU, LC-40LE700S, LC-40LX
700E, LC-40LX700RU, LC-40LU700E,
LC-40LU700S
LCD panel
Advanced Super View & BLACK TFT
LCD (32")
Advanced Super View & BLACK TFT
LCD (40")
Resolution 2,073,600 pixels (1,920 x 1,080)
Video colour system AL/SECAM/NTSC 3.58/NTSC 4.43/PPAL 60
TV function
TV-standard
Analogue CCIR (B/G, I, D/K, L/L")
Digital DVB-T (2K/8K OFDM), DVB-C
Receiving
channel
VHF/UHF
IR A ch_E69 ch (Digital), E2_E69 ch, F2_F10 ch, I21_I69 ch, IR A_IR J ch
CATV
Hyper-band, S1_S41 ch
TV-tuning system
Auto Preset 999 ch (non-Nordic [DTV]), Auto Preset 9999 ch (Nordic [DTV]),
Auto Preset 99 ch (ATV), Auto Label, Auto Sort
STEREO/BILINGUAL NICAM/A2
Audio amplifier 10 W x 2
Speaker (35 mm x 100 mm) x 2
Terminals
Antenna
UHF/VHF 75
Din type (analogue & digital)
RS-232C D-Sub 9 pin male connector
EXT 1 SCART (AV input, Y/C input, RGB input, TV output)
EXT 2 SCART (AV input/monitor output, Y/C input)
EXT 3 COMPONENT IN (Y/P
B (C B )/P R (C R ), RCA pin (AUDIO R/L))
EXT 4 15 pin mini D-sub
HDMI 1 (EXT 5) HDMI
HDMI 2 (EXT 6) HDMI
HDMI 3 (EXT 7) HDMI
HDMI 4 (EXT 8) HDMI
EXT 9 RCA pin (AV input)
USB USB
HDMI 2/PC AUDIO (R/L) Ø 3.5 mm jack*
DIGITAL AUDIO OUTPUT Optical S/PDIF digital audio output
C. I. (Common Interface) EN50221, R206001
OUTPUT
RCA pin (AUDIO R/L)
Headphones Ø 3.5 mm jack (audio output)
OSD language
Czech, Danish, Dutch, English, Estonian, Finnish, French, German, Greek,
Hungarian, Italian, Latvian, Lithuanian, Norwegian, Polish, Portuguese,
Russian, Slovak, Slovene, Spanish, Swedish, Turkish, Ukrainian
Power requirement
AC 220_240 V, 50 Hz
Power consumption (method IEC62087) 93 W (0.2 W standby) 133 W (0.2 W standby)
Weight
10.5 kg (without stand), 13.5 kg (with
stand)
12.3 kg (without stand), 16.2 kg (with
stand)
Operating temperature
0°Cto+40°C

Sharp LC-52LE700E Specifications

General

Display diagonal	52 \
Display brightness	450 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Viewable size diagonal	1320 mm
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	4000:1
Viewing angle, horizontal	176 °
Power requirements	AC 220-240 V / 50 Hz
RS-232 ports	1
HDMI ports quantity	4
SCART ports quantity	2
Component video (YPbPr/YCbCr) in	3
Product color	Black
Tuner type	Analog & digital
Analog signal format system	NTSC

Weight and Dimensions

Depth (without stand)	95 mm
Width (without stand)	1238 mm
Height (without stand)	765 mm
Weight (without stand)	27600 g
