Sharp LC-52LE700E Service Manual

LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S
14
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
R3368 VRS-CZ1JF680JY AB J Resistor 68 1/16W Metal Oxide
R3369 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3370 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3371 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3372 VRS-CZ1JF680JY AB J Resistor 68 1/16W Metal Oxide
R3373 VRS-CZ1JF680JY AB J Resistor 68 1/16W Metal Oxide
R3374 VRS-CZ1JF680JY AB J Resistor 68 1/16W Metal Oxide
R3375 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3376 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3377 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3378 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3379 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3380 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3381 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3382 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3383 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3384 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3389 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3390 VRS-CZ1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
R3395 VRS-CZ1JF391JY AA J Resistor 390 1/16W Metal Oxide
R3396 VRS-CZ1JF391JY AA J Resistor 390 1/16W Metal Oxide
R3501 VRK-SA1JF000JY AB J Resistor 0 1/16W Metal Composition
R3502 VRK-SA1JF000JY AB J Resistor 0 1/16W Metal Composition
R3503 VRK-SB1FF100JY AA J Resistor 10 1/32W Metal Composition
R3504 VRK-SB1FF100JY AA J Resistor 10 1/32W Metal Composition
R3505 VRK-SB1FF100JY AA J Resistor 10 1/32W Metal Composition
R3506 VRK-SB1FF100JY AA J Resistor 10 1/32W Metal Composition
R3507 VRK-SB1FF100JY AA J Resistor 10 1/32W Metal Composition
R3508 VRK-SB1FF100JY AA J Resistor 10 1/32W Metal Composition
R3509 VRS-CZ1JF102FY AA J Resistor 1k 1/16W Metal Oxide
R3510 VRS-CZ1JF102FY AA J Resistor 1k 1/16W Metal Oxide
R3511 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R3512 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R4404 VRS-CZ1JF103JY AA J
Resistor 10k 1/16W Metal Oxide
R4405 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R4406 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R4407 VRK-SA1JF000JY AB J Resistor 0 1/16W Metal Composition
R4408 VRS-CG1JF000JY AB J Resistor 0 1/16W Metal Oxide
R4409 VRS-CZ1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4410 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R4411 VRS-CG1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4413 VRS-CZ1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4414 VRS-CG1JF101JY AA J Resistor 100 1/16W Metal Oxide
R4415 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R4416 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R4418 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R4419 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R4420 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R4421 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R4422 VRS-CZ1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4423 VRS-CZ1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4424 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R4425 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R4426 VRS-CZ1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4427 VRS-CZ1JF101JY AA J Resistor 100 1/16W Metal Oxide
R4428 VRS-CZ1JF333JY AA J Resistor 33k 1/16W Metal Oxide
R4429 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R4430 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R4431 VRS-CG1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4432 VRS-CG1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4433 VRS-CG1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4434 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R4435 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R4436 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R4437 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R4438 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R4439 VRS-CZ1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4440
VRS-CZ1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4441 VRS-CZ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R4442 VRS-CG1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4443 VRS-CG1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4444 VRS-CG1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4445 VRS-CG1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4446 VRS-CG1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4447 VRS-CG1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4448 VRS-CZ1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4449 VRS-CZ1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4450 VRS-CZ1JF470JY AA J Resistor 47 1/16W Metal Oxide
R4451 VRS-CZ1JF105JY AA J Resistor 1M 1/16W Metal Oxide
R4452 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R4453 VRS-CZ1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
R4455 VRS-CZ1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
R4456 VRS-CZ1JF472JY AA J Resistor 4.7k 1/16W Metal Oxide
R4457 VRS-CZ1JF000JY AA J Resistor 0 1/16W Metal Oxide
R4458 VRS-CG1JF470JY AA J Resistor 47 1/16W Metal Oxide
[3] DUNTKE306FM01 (MAIN Unit)

Sharp LC-52LE700E Specifications

General

Display diagonal	52 \
Display brightness	450 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Viewable size diagonal	1320 mm
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	4000:1
Viewing angle, horizontal	176 °
Power requirements	AC 220-240 V / 50 Hz
RS-232 ports	1
HDMI ports quantity	4
SCART ports quantity	2
Component video (YPbPr/YCbCr) in	3
Product color	Black
Tuner type	Analog & digital
Analog signal format system	NTSC

Weight and Dimensions

Depth (without stand)	95 mm
Width (without stand)	1238 mm
Height (without stand)	765 mm
Weight (without stand)	27600 g
