Sharp LC-52LE700E Service Manual

LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S
16
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
SC1502 QSOCZA173WJQZY AG J Socket
SC1503 QSOCZA173WJQZY AG J Socket
SC1505 QSOCZA173WJQZY AG J Socket
SC4401 Not Available - - Connector
TH2001 VHHM1103J03-1Y AC J Thermistor
!
TU1101 RTUDAA019WJQZ AZ J Tuner
VA501 RH-VXA005WJZZY AA J Varistor AVR-M1005C270MTABB
VA502 RH-VXA005WJZZY AA J Varistor AVR-M1005C270MTABB
VA503 RH-VXA005WJZZY AA J Varistor AVR-M1005C270MTABB
VA506 RH-VXA005WJZZY AA J Varistor AVR-M1005C270MTABB
VA507 RH-VXA005WJZZY AA J Varistor AVR-M1005C270MTABB
VA508 RH-VXA005WJZZY AA J Varistor AVR-M1005C270MTABB
VA509 RH-VXA005WJZZY AA J Varistor AVR-M1005C270MTABB
VA510 RH-VXA005WJZZY AA J Varistor AVR-M1005C270MTABB
VA3301 RH-VXA074WJZZY AB J Varistor AVRL101A1R1NTB
VA3302 RH-VXA074WJZZY AB J Varistor AVRL101A1R1NTB
X1101 RCRSCA101WJZZY AG J Crystal
X2001 RCRSC0032TAZZY AG J Crystal
X2002 RFILZA023WJQZY AD J Filter
X3302 RCRSCA101WJZZY AG J Crystal
X4401 RCRSCA101WJZZY AG J Crystal
[4] DUNTKE266FM18 (KEY Unit)
D151 RH-EX0646GEZZY AA J Zener Diode MTZJT-7215B
D152 RH-EX0646GEZZY AA J Zener Diode MTZJT-7215B
D155 RH-EX0646GEZZY AA J Zener Diode MTZJT-7215B
P151 QPLGNA059WJZZ AC J Plug
R151 VRD-RA2BE822JY AA J Resistor 8.2k 1/8W Carbon
R152 VRD-RA2BE123JY AA J Resistor 12k 1/8W Carbon
R153 VRD-RA2BE822JY AA J Resistor 8.2k 1/8W Carbon
R154 VRD-RA2BE123JY AA J Resistor 12k 1/8W Carbon
S151 QSW-K0003AJZZ+ AB J Switch
S152 QSW-K0003AJZZ+ AB J Switch
S153 QSW-K0003AJZZ+ AB J Switch
S154 QSW-K0003AJZZ+ AB J Switch
S155 QSW-K0003AJZZ+ AB J Switch
S156 QSW-K0003AJZZ+ AB J Switch
S157 QSW-K0003AJZZ+ AB J Switch
[5] DUNTKF308FM02 (R/C, LED Unit)
C101 VCKYCY1HF103ZY AA J Capacitor 0.01 50V Ceramic
C102 VCEASX1CN106MY AC J Capacitor 10 16V Electrolytic
C103 VCEASY1CN107MY AC J Capacitor 100 16V Electrolytic
C104 VCKYTV1CF225ZY AB J Capacitor 2.2 16V Ceramic
D102 RH-PX0421CEZZY AD J Diode CL-165HR/YG-D-T
D103 RH-PX0421CEZZY AD J Diode CL-165HR/YG-D-T
D104 RH-EXA092WJZZY AB J Zener Diode UDZSFVTE-1712B
FB101 RBLN-A375WJQZY AA J Ferrite Core
IC101 VHIGA1S100W-1Y AE J IC GA1A1S100WP
P101 QPLGNA322WJZZY AC J Plug
P102 QPLGNA330WJZZY AD J Plug
Q102 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q104 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q106 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
Q107 VS2SC3928AR-1Y AB J Transistor 2SC3928A-T112-1R
R103 VRS-CY1JF161JY AA J Resistor 160 1/16W Metal Oxide
R106 VRS-CY1JF223JY AA J Resistor 22k 1/16W Metal Oxide
R113 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
R114 VRS-CY1JF161JY AA J Resistor 160 1/16W Metal Oxide
R117 VRS-CY1JF821JY AA J Resistor 820 1/16W Metal Oxide
R118 VRS-CY1JF103JY AA J Resistor 10k 1/16W Metal Oxide
R119 VRS-CY1JF393JY AA J Resistor 39k 1/16W Metal Oxide
R120 VRS-CY1JF101JY AA J Resistor 100 1/16W Metal Oxide
R121 VRS-CY1JF000JY AA J Resistor 0 1/16W Metal Oxide
R123 VRS-CY1JF273JY AA J Resistor 27k 1/16W Metal Oxide
R124 VRS-CJ1JF103JY AA J Resistor 10k 1/16W Metal Oxide
RMC101 RRMCUA053WJZZ AE J Remote Receiver
SLD101 PSLDPA076WJFW AD J Shield
[6] DUNTKF314FM02 (ICON Unit)
D201 RH-PXA129WJQZY AF J Diode SML012BCTT86T
P201 QPLGNA322WJZZY AC J Plug
R202 VRS-CZ1JF221JY AA J Resistor 220 1/16W Metal Oxide
[3] DUNTKE306FM01 (MAIN Unit)

Sharp LC-52LE700E Specifications

General

Display diagonal	52 \
Display brightness	450 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Viewable size diagonal	1320 mm
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	4000:1
Viewing angle, horizontal	176 °
Power requirements	AC 220-240 V / 50 Hz
RS-232 ports	1
HDMI ports quantity	4
SCART ports quantity	2
Component video (YPbPr/YCbCr) in	3
Product color	Black
Tuner type	Analog & digital
Analog signal format system	NTSC

Weight and Dimensions

Depth (without stand)	95 mm
Width (without stand)	1238 mm
Height (without stand)	765 mm
Weight (without stand)	27600 g
