Sharp LC-52LE700E Service Manual

LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S
6 – 8
No sound from external input devices (4)
Does not the sound of the audio signal input to EXT8 go out?
Is there a audio input signal in pins(5/CVBS_IN_L) and (4/
CVBS_IN_R) of EXT8(J506)?
NO Check the setting of an external input device that connects with
EXT8.
YES
Is there a audio input signal in pins (R28/CVBS_L) and (T28/
CVBS_R) of IC3302 (Digital AV decode & Main CPU) from J505?
NO Check IC3302 and its peripheral circuits.
YES
Refer to “No sound output in all modes”.
No sound from external input devices (5)
Does not the sound of the audio signal input to EXT4/5/6 (HDMI) go out?
Does not the picture/sound of the HDMI signal input to HDMI-1/2/3 go out?

Sharp LC-52LE700E Specifications

General

Display diagonal	52 \
Display brightness	450 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Viewable size diagonal	1320 mm
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	4000:1
Viewing angle, horizontal	176 °
Power requirements	AC 220-240 V / 50 Hz
RS-232 ports	1
HDMI ports quantity	4
SCART ports quantity	2
Component video (YPbPr/YCbCr) in	3
Product color	Black
Tuner type	Analog & digital
Analog signal format system	NTSC

Weight and Dimensions

Depth (without stand)	95 mm
Width (without stand)	1238 mm
Height (without stand)	765 mm
Weight (without stand)	27600 g
