Sharp LC-52LE700E Service Manual

LC-32/40/46LE700E/RU/S,LU700E/S,LX700E/RU,LC-52LE700E/RU/S
7 – 6
62 VSS - GND
63 RS_ON O Power control for RS-232C Circuit
64 SY(N.C.)_DET O No function
65 HDMI_SCDT I No function
66 POW_SW O Power Key Detection
67 (N.C.) No function
68 (N.C.) No function
69 PL_POW O Panel Power ON
70 (N.C.)
71 CSEN2 I No function
72 AC_DET I Detection for Power moment stop
73 VSY(N.C.)/DETECT I No function
74 CBOOT O/D Main CPU boot change
75 TXD_CPU O MAIN CPU communication signal output
76 RXD_CPU I MAIN CPU communication signal input
77 PM_REQ O Communication Reset
78 SRESET O/D Main CPU Reset
79 OPC I OPC input
80 QSTEMP I Thermistor Input
81 AFT/AGC I No function
82 KEY1 I Key operation input
83 KEY2 I Key operation input
84 KEY3 I No function
85 (N.C.) I No function
86 MAIN_TEMP I No function
87 (N.C.) I No function
88 PNL_DET6 I No function
89 PNL_DET5 I No function
90 PNL_DET4 I No function
91 PNL_DET3 I No function
92 PNL_DET2 I No function
93 PNL_DET1 I No function
94 AVSS - GND
95 PNL_DET0 I No function
96 VRFF - Analogue reference voltage
97 AVCC - Analogue power supply
98 LED_R O Red LED ON/OFF
99 LED_G O LED_Green ON/OFF
100 LED_OPC O OPC_LED On/OFF
Pin No. Pin Name I/O Pin Function

Sharp LC-52LE700E Specifications

General

Display diagonal	52 \
Display brightness	450 cd/m²
Display technology	LCD
Native aspect ratio	16:9
Viewable size diagonal	1320 mm
Contrast ratio (dynamic)	3000000:1
Contrast ratio (typical)	4000:1
Viewing angle, horizontal	176 °
Power requirements	AC 220-240 V / 50 Hz
RS-232 ports	1
HDMI ports quantity	4
SCART ports quantity	2
Component video (YPbPr/YCbCr) in	3
Product color	Black
Tuner type	Analog & digital
Analog signal format system	NTSC

Weight and Dimensions

Depth (without stand)	95 mm
Width (without stand)	1238 mm
Height (without stand)	765 mm
Weight (without stand)	27600 g
