Sharp LC-60LE600U - Major Service Parts; Outline

LC-60/70LE600U
iv
LC-60LE600U
Service Manual
OUTLINE
MAJOR SERVICE PARTS
PWB Unit
OTHER Unit
IC For Exclusive Use Of The Service
Service Jigs
Ref No. Parts No. Description
N DKEYMF905FM04 MAIN Unit
N DUNTKG015FM01 R/C, OPC Unit
N DUNTKG014FM01 ICON Unit
N DUNTKF800FM53 KEY Unit
N RUNTKB057WJQZ
POWER/LED DRIVER Unit (RUNTKB057WJQZ is completely interchangeable with RUNTKA932WJQZ.)
(LC-60LE600U)
N RUNTKA933WJQZ POWER/DRIVER Unit (LC-70LE600U)
N DUNTKF908FM04 LCD CONTROL Unit
Ref No. Parts No. Description
N R1LK600D3GV0BZ 60" LCD Panel Module Unit (LK600D3GV0BZ)
N R1LK695D3GW8BD 70" LCD Panel Module Unit (LK695D3GW8BD)
Ref No. Parts No. Description Q'ty
IC508 RH-iXD397WJQZS IC S-24CS02AFJ-TB-G (RGB) 1
IC1503 RH-iXD394WJQZS IC S-24CS02AFJ-TB-G (HDMI1) 1
IC1504 RH-iXD396WJQZS IC S-24CS02AFJ-TB-G (HDMI3) 1
IC1505 RH-iXD395WJQZS IC S-24CS02AFJ-TB-G (HDMI2) 1
Ref No. Parts No. Description Q'ty
N QCNW-C222WJQZ Connecting Cord L=1000mm 80pins, LCD Control Unit to LCD Panel Unit 2
N QCNW-F676WJQZ Connecting Cord L=1000mm 41pins, MAIN Unit to LCD Control Unit (LW) 1
N QCNW-N033WJZZ Connecting Cord L=1000mm, 24-12/4pins, Main to LCD Control Unit (PD) 1
