Sharp LC-60LE650U User Manual

LC-60/70LE650U/C6500U/LE657U,LC-60/70LE755U/LE757U/LE857U/C7500U
8
NO. PARTS CODE
PRICE
RANK
NEW
MARK
PART
DELIVERY
DESCRIPTION
IC1501 VHiHSP0618M-1Y AE J HSP061-8M16
IC1502 VHiHSP0618M-1Y AE J HSP061-8M16
IC1503 VHiHSP0618M-1Y AE J HSP061-8M16
IC1504 VHiHSP0618M-1Y AE J HSP061-8M16
IC1507 VHiPS2553DB-1Y AE J TPS2553DBVR
IC1508 VHiLVC1G08W-1Y AD J 74LVC1G08GW,125
IC1509 VHiLVC1G08W-1Y AD J 74LVC1G08GW,125
IC1510 VHiLVC1G08W-1Y AD J 74LVC1G08GW,125
IC1702 VHiAK4201EU-1Y AL J AK4201EUP
IC1703 VHiYSS952QZ-1Y AQ J YSS952-QZE2
IC1901 VHiYDA164EZ-1Y AL J YDA164CZ-QZE2
IC1902 VHiYDA164EZ-1Y AL J YDA164CZ-QZE2
IC1903 VHi3411A18N-1Y X MM3411A18NRE
IC2001 VHiLVC2G126-1Y AD J 74LVC2G126DP,125
IC2002 VHiLCX157FT-1Y AD J TC74LCX157FT(ELK,M
IC2003 VHiBU4227G+-1Y AE J BU4227G-TR
IC2004 RH-iXD515WJN7Q J R5F21368CNFP
IC2005 VHiLCX125FT-1Y AD J TC74LCX125FT(ELK,M
IC2007 VHiRV2402Ai-1Y AB J R1EV24002ASAS0I
IC2008 VHiAHC1G08W-1Y AD J 74AHC1G08GW/G,125
IC2009 VHiLVC1G00W-1Y AC J 74LVC1G00GW,125
IC2601 VHiSii9387A-1Q AN J SII9387ACTUC
IC2602 VHiS172B12U-1Y AD J S-1172B12-U5T1G
IC3102 VHiAHC1G08W-1Y AD J 74AHC1G08GW/G,125
IC3103 Not Available - -
S34ML04G100TFI000 (Please replace the MAIN PWB when it is necessary to replace
this IC.)
IC3104 Not Available - -
R1EV24064ASAS0I (Please replace the MAIN PWB when it is necessary to replace this
IC.)
IC3301 RH-iXD414WJN1Q BE X MT5396SGDJ
IC3302 VHiS172B12U-1Y AD J S-1172B12-U5T1G
IC3303 VHi3411A33N-1Y AC J MM3411A33NRE
IC3501 RH-iXD555WJQZQ AN J K4B2G1646E-BCK0
IC3502 RH-iXD555WJQZQ AN J K4B2G1646E-BCK0
IC3503 RH-iXD555WJQZQ AN J K4B2G1646E-BCK0
IC3504 RH-iXD555WJQZQ AN J K4B2G1646E-BCK0
IC3802 V
HiHC2G66DP-1Y AD J 74HC2G66DP,125
IC3805 VHiHC2G66DP-1Y AD J 74HC2G66DP,125
IC9501 VHiPS2553DB-1Y AE J TPS2553DBVR
IC9502 VHiBD2246G+-1Y AD J BD2246G-GTR
IC9601 VHiBD9328EF-1Y AF J BD9328EFJ-E2
IC9603 VHiTPS54429-1Y AH J TPS54229PWPR
IC9604 VHiTPS54227-1Y AF J TPS54227DDAR
IC9605 VHi3411A33N-1Y AC J MM3411A33NRE
IC9606 VHiTPS54227-1Y AF J TPS54227DDAR
IC9607 VHiTPS54429-1Y AH J TPS54229PWPR
J501 QJAKEA111WJQZY AD J Jack
J504 QJAKEA115WJQZQ AE J Jack
J510 QJAKZA125WJN1 AE X Jack
J9401 QJAKZA128WJQZQ AF J Jack
J9501 QSOCZA265WJQZY AE J Socket
J9502 QSOCZA265WJQZY AE J Socket
L1107 VPRHR100MR47NY AB J Peaking 10µH
L1502 VPMTN1R0JR35NY AA J Peaking 1.0µH
L1902 RCiLPB106WJZZY AC J Coil
L1903 RCiLPB106WJZZY AC J Coil
L1904 RCiLPB106WJZZY AC J Coil
L1906 RCiLPB106WJZZY AC J Coil
L1907 RCiLPB106WJZZY AC J Coil
L1908 RCiLPB106WJZZY AC J Coil
L2501 RCiLFA294WJZZY AB J Coil
L2502 RCiLFA294WJZZY AB J Coil
L2503 RCiLFA294WJZZY AB J Coil
L2504 RCiLFA294WJZZY AB J Coil
L3801 RCiLFA294WJZZY AB J Coil
L3802 RCiLFA294WJZZY AB J Coil
L3803 RCiLFA294WJZZY AB J Coil
L3804 RCiLFA294WJZZY AB J Coil
L9501 R
CiLFA294WJZZY AB J Coil
L9502 RCiLFA294WJZZY AB J Coil
L9503 RCiLFA294WJZZY AB J Coil
L9504 RCiLFA294WJZZY AB J Coil
L9505 RCiLFA294WJZZY AB J Coil
L9601 RCiLPB015WJQZY AC J Coil
L9602 RCiLPA754WJQZY AD J Coil
L9603 RCiLPB011WJQZY AC J Coil
L9604 RCiLPB011WJQZY AC J Coil
L9605 RCiLPB011WJQZY AC J Coil
P1903 QPLGNA906WJZZY AE J Plug
P1904 QPLGNA903WJZZY AC J Plug
P2001 QPLGNB062WJZZY AC J Plug
P2002 QPLGNB050WJZZY AC J Plug
P3801 QPLGNB001WJZZ AE J Plug
Q505 VSRT1N141C/-1Y AB J RT1N141U-T112-1
Q506 VSiMH23T110-1Y AC J IMH23T110
Q510 VSiSA1530AC-1Y AA J ISA1530AC1-T112V-1R
[2] DKEYMF953FM06 (MAIN Unit)

Sharp LC-60LE650U Specifications

General

Display diagonal	60 \
Native aspect ratio	16:9
Native refresh rate	120 Hz
LED backlighting type	Edge-Lit LED
Supported video modes	1080p
Contrast ratio (dynamic)	4000000:1
Viewing angle, horizontal	176 °
3D	No
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
HDMI version	1.4
HDMI ports quantity	4
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in	1
Consumer Electronics Control (CEC)	Aquos Link
Electronic Program Guide (EPG)	-
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	- W
Power consumption (typical)	188 W
Sustainability certificates	ENERGY STAR

Weight and Dimensions

Depth (with stand)	360 mm
Height (with stand)	851 mm
Weight (with stand)	28000 g
Depth (without stand)	77 mm
Width (without stand)	1379 mm
Height (without stand)	826 mm
Weight (without stand)	25000 g
