Sharp LC55UB30U - Page 58

CONFIDENTIAL – DO NOT COPY
Page 13-2
File No. SG-0000361
Child P/N Specification Circuit Number Qty M/S
9LE 098001060380
Tuner silicon can ST45WN-6A-E Horizontal 1input
(GSD)LF
TU1 1
9LE 010201011210 E/C TK 100uF 16V 105'C NF (5*11mm) L-F
CE13,CE21,CE24,CE27,CE30,C
E31,CE34,CE35,CE36,CE38,CE
39,CE41,CE42
13
9LE 010152211310 E/C TL 220uF 25V 105'C NF 8*11.5mm L-F
CE1,CE5,CE6,CE7,CE9,CE11,C
E14,CE15,CE18,CE19,CE20,CE
23,CE25,CE26,CE40
15
9LE 010202211210 E/C TK 220uF 16V 105'C NF (6.3*11mm) L-F
CE2,CE4,CE12,CE16,CE17,CE
22,CE28,CE29,CE32,CE33,CE3
7,CE43
12
9LE 030310023517
CONN B TO FPC 0.5mm 51P 90' SMD(196334-51041-3)
HF
J5 1 M
9LE 030310023516
CONN B TO FPC 0.5mm 51P 90'
SMD(FBSNL05002N51) HF
J5 1 S
9LE 030410000510
CONN HDMI 19P 90' SMD WITH SPRING
(1165-2CG04-24P) HF
P3,P4,P5,P6 4
9LE 035410000150 X'FMR LAN FILTER SMD 16PIN U37 1 M
9LE 035410000190 X'FMR LAN 10/100Base-T (NS601683) SMD LF U37 1 S
9LE 036020100150 PWR IND 10uH 3.1A (MNR-8040-100M) LF L4 1 M
9LE 036020100170 PWR IND. 10uH 3.2A(LVS808040L-100M-N) LF L4 1 S
9LE 036020159750
PWR IND. 1.5uH 10.5A
10x10x5mm(MSCDRI-105R-1R5N) LF
L22 1
9LE 036020229550 PWR IND. 2.2uH 4.8A (MNR-6045-2R2N-E) LF L2,L3,L8,L23,L25 5 M
9LE 036023229520
PWR IND. 2.2uH 5.1A 6x6x4.5mm (VLS6045EX-2R2N)
HF
L2,L3,L8,L23,L25 5 S
9LE 036021229120 PWR IND. 2.2uH 6.7A(VLP8040T-2R2N) LF L6,L11 2 M
9LE 036020229170 PWR IND. 2.2uH 7.2A(LVS808040L-2R2M-N) LF L6,L11 2 S
9LE 036023100520
PWR IND. 10uH 3.4A 6x6x4.5mm(VLS6045EX-100M)
HF
L37,L41,L51,L56 4 M
9LE 036020100270 PWR IND. 10uH 3.2A(LVS606045L-100M-N) LF L37,L41,L51,L56 4 S
9LE 039050042343 GEN. DIODE LL4148WP (CD4148WP) SMD 1206 LF D2,D6,D12 3 M
9LE 039050071293 DIODE FAST 0.3A 100V 1N4148W-7-F SOD-123 HF D2,D6,D12 3 S
9LE 039060050293 Schottky Diode 0.2A 30V BAT54C-7-F SOT-23 HF D3,D7,D9,D18 4 M
9LE 039060110273 Schottky Diode 0.2A 30V BAT54C SOT-23 HF D3,D7,D9,D18 4 S
9LE 039060086413
SCHOTTKY DIODE 0.2A 30V SCS520S SOD-523 2PIN
LF
D14 1 M
9LE 039060086203 SCHOTTKY DIODE 0.2A 30V RB520S-30F SOD-523 LF D14 1 S
