Sharp LC55UB30U - Page 59

CONFIDENTIAL – DO NOT COPY
Page 13-3
File No. SG-0000361
Child P/N Specification Circuit Number Qty M/S
9LE 040005415012 ZENER 5.49~5.73V UDZSTE-175.6B 1/5W SOD-323 D5,D8,D10,D11, D20,D34 6 M
9LE 040005415717 ZENER 5.49~5.73V KDZ5.6VY 1/5W SOD-323 LF D5,D8,D10,D11, D20,D34 6 S
9LE 040008212715
ZENER 8.27V-9.14V MMSZ5238B-7-F 1/2W SOD-123
LF
ZD1 1 M
9LE 040008512016 ZENER RLZ9V1B 8.57~9.01V 1/2W LL-34 LF ZD1 1 S
9LE 040013815713 ZENER 13.8-15.6V BZT52C15S-7-F 1/5W SOD-323 LF D1 1 M
9LE 040014215010 ZENER 14.25-15.75V MM3Z15VCWF 1/5W SOD-323 LF D1 1 S
9LE 041050005638 TR NPN 0.2A 40V LMBT3904LT1G SOT-23 HF
Q3,Q4,Q5,Q8,Q12,Q14,Q16,Q1
8,Q19,Q20,Q21,Q22,Q26,Q28,Q
29
15 M
9LE 041050005643 TR NPN 0.2A 40V METR3904-G SOT-23 HF
Q3,Q4,Q5,Q8,Q12,Q14,Q16,Q1
8,Q19,Q20,Q21,Q22,Q26,Q28,Q
29
15 S
9LE 042010049630
MOSFET N-CH 2N7002-7-F 115mA 60V SMD (SOT-23)
L-F
Q6,Q7,Q9,Q17 4 M
9LE 042010126611 MOSFET N-CH 300mA 60V 2N7002 SOT-23 HF Q6,Q7,Q9,Q17 4 S
9LE 042020073636 MOSFET P-CH 9.5A 30V SSG4835P SOP 8PIN LF U17 1 M
9LE 042020093642 MOSFET P-CH 9A 30V APM4317KC-TRG SOP-8 HF U17 1 S
9LE 043050322985 IC MEMC MST7410DY BGA-960 BALL HF U11 1
9LE 043060270079 IC LDO 1A ADJ AP1117EG-13 SOT223-3L 3PIN HF U27,U32 2 M
9LE 043060345075 IC LDO 1A ADJ AX1007EA SOT223-3L HF U27,U32 2 S
9LE 043060389715
IC STEP-DOWN DC/DC CONV 6A 6V TPS54618RTER
WQFN 3x3-16 HF
U3,U9 2
9LE 043060454044
IC STEP-DOWN DC/DC CONV 3A 23V IT76630M-1
SOP8-EP LF
U1 1 M
9LE 0430604260C1
IC STEP-DOWN CONV 3A 23V FR9889SPCTR SOP-8
LF
U1 1 S
9LE 043060467752
IC STEP-DOWN CONV 8A 18V RT7299BHGQW
WQFN-14AL HF
U15 1
9LE 043070865615 IC AUDIO OP DRV632PWR TSSOP-14 HF U38 1
9LE 043070942715
C AUDIO POWER AMP 20W TAS5707LPHPR
HTQFP-48 HF
U26 1
9LE 043070956079 IC RESET 4.38V APX810-44SAG-7 SOT-23 HF Q11,Q27 2
9LE 043070995079 IC POWER SWITCH 1A AP2161WG-7 SOT-25 HF U12,U14,U33 3
9LE 043140035985 IC SCALER MSD95C0H-5-002B BGA-1286 BALL HF U28 1
9LE 043160021903
IC DDR3 64Mx16 NT5CB64M16FP-EK TFBGA-96 BALL
HF
U4,U10 2
