Sharp LC55UB30U User Manual

CONFIDENTIAL – DO NOT COPY
Page 13-4
File No. SG-0000361
Child P/N Specification Circuit Number Qty M/S
9LE 043170022960
IC eMMC NAND FLASH 4GB MTFC4GMCDM-1M WT
TFBGA-153 LF
U35 1
9LE 043060461075
IC 2A DDR TERMINATION REGULATOR AX1250ESA
SOP-8L-EP LF
U7,U20,U21 3 M
9LE 043060449071
IC 2A DDR TERMINATION REGULATOR
APL5337KAI-TRG SOP-8P HF
U7,U20,U21 3 S
9LE 043060460052
IC STEP-DOWN CONV 3.5A 18V RT7295AGJ6F
TSOT-23-6 HF
U2,U6,U8,U18,U19 5
9LE 043160024903
IC DDR3 128Mx16 NT5CB128M16FP-EK BGA-96 BALL
HF
U22,U23,U24,U25 4
9LE 043160028903
IC DDR3 4Gb 256Mx16 NT5CB256M16DP-EK BGA-96
BALL HF
U30,U31 2
9LE 043000016609 IC CMOS LOGIC 74HC4052PW TSSOP 16PIN LF U40 1 M
9LE 043000038686 IC CMOS ANALOG U74HC4052G-P16-R TSSOP-16 HF U40 1 S
9LE 043030163045 IC SERIAL FLASH 32M MX25L3206EM2I-12G SOP-8 LF U39 1
9LE 050006050850 LPB ASS'Y FSP-171-3PSZ01S for SHARP LC-55UB30U 1
9LE 098001490010 IR Blaster USB Dongle TRX FOR SHARP LF 1
9LE 098003063230
REMOTE IR 38KHZ 32KEY GJ221-U W/BATTERY FOR
SHARP LF
1
9LE 171204002170 HEAT SINK (AL)(SV370XVT)(SV320XVT) U28H 1
9LE 171204002260 HEAT SINK(AL/46*46*7)(E470VL-TW) U11H 1
9LE 180101530010
FRONT BEZEL(PCABS+GF15
FR/T52013)(LC-55UB30U)ASS'Y
1
9LE 180102557010
REAR COVER(PC+ABS
FR/T52013)(LC-55UB30U)ASS'Y
1
9LE 180104304010
DISPLAY KEY(PC+ABS
FR/T52013)(LC-55UB30U)ASS'Y
1
9LE 180119887010
MIDDLE FRAME(PC+ABS
FR/T52013)(LC-55UB30U)ASS'Y
1
9LE 181201028910 SPK SUPPORT BKT_L(SGCC 1.0t)(LC-55UB30U)ASS'Y 1
9LE 181201028920
SPK SUPPORT BKT_R(SGCC
1.0t)(LC-55UB30U)ASS'Y
1
9LE 181304022011 BASE BKT_L(SGCC 2.0t)(LC-55UB30U)ASS'Y 1
9LE 181304023011 BASE BKT_R(SGCC 2.0t)(LC-55UB30U)ASS'Y 1
9LE 181304032020 NECK BKT(SGCC 2.0t)(LC-65LE654U)ASS'Y 2
9LE 192510018580 EPS FOAM_TL(LC-55UB30U) 1
9LE 192510018590 EPS FOAM_TR(LC-55UB30U) 1
9LE 192510018600 EPS FOAM_BL(LC-55UB30U) 1

Sharp LC55UB30U Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	55 \
Display brightness	- cd/m²
LED backlighting type	Direct-LED
Contrast ratio (dynamic)	4000000:1
Screen format adjustments	16:9
Supported graphics resolutions	3840 x 2160
Motion interpolation technology	AquoMotion 120
3D	-
Tuner type	Analog & digital
Analog signal format system	NTSC
Digital signal format system	ATSC
RMS rated power	20 W
Number of speakers	2
PC in (D-Sub)	No
HDMI ports quantity	4
DVI-D ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Number of OSD languages	3
On Screen Display (OSD) languages	ENG, ESP, FRE
Product color	Black
Panel mounting interface	400 x 400 mm
AC input voltage	120 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	- W
Sustainability certificates	ENERGY STAR
Package depth	151.892 mm
Package width	1445.006 mm
Package height	819.912 mm
Package weight	Weight of the packaged product in gram.

Weight and Dimensions

Depth (with stand)	325.882 mm
Height (with stand)	757.174 mm
Weight (with stand)	20003.42 g
Depth (without stand)	71.882 mm
Width (without stand)	1246.886 mm
Height (without stand)	722.122 mm
Weight (without stand)	19005.52 g
