Sharp LC55UB30U - Page 69

Level
Child P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
6 *R* 9LE 011231815107 C/M Multi. 180PF 50V NPO J 0402 G Assembly Pull EA 1
6 *R* 9LE 011551815107 C/M Multi. 180PF 50V NPO J 0402 G Assembly Pull EA 1
6 1 9LE 011132205107 C/M Multi. 22PF 50V NPO J 0402 G Assembly Pull EA 8 C216,C217,C366,C367,C478,C479,C482,C490
6 *R* 9LE 011552205107 C/M Multi. 22PF 50V NPO 0402 samsung G Assembly Pull EA 8
6 *R* 9LE 011232205107 C/M Multi. 22PF 50V NPO J 0402 G Assembly Pull EA 8
6 1 9LE 011132715107 C/M Multi. 270PF 50V NPO J 0402 G Assembly Pull EA 2 C474,C477
6 *R* 9LE 011232715107 C/M Multi. 270PF 50V NPO 0402 G Assembly Pull EA 2
6 *R* 9LE 011552715107 C/M Multi. 270PF 50V NPO J 0402 G Assembly Pull EA 2
6 1 9LE 011133335116 C/M MULTI 0.033uF 50V X7R 0603 G Assembly Pull EA 4 C354,C361,C363,C373
6 *R* 9LE 011233335116 C/M MULTI 0.033uF 50V X7R 0603 G Assembly Pull EA 4
6 *R* 9LE 011553335116 C/M MULTI 0.033uF 50V X7R 0603 G Assembly Pull EA 4
6 1 9LE 011133925117 C/M Multi. 3900PF 50V X7R K 0402 G Assembly Pull EA 1 C9
6 *R* 9LE 011233925117 C/M Multi. 3900PF 50V X7R K 0402 G Assembly Pull EA 1
6 1 9LE 011134715107 C/M Multi. 470pF 50V NPO J 0402 G Assembly Pull EA 8 C135,C47,C487,C488,C489,C493,C494,C495
6 *R* 9LE 011554715107 C/M Multi. 470pF 50V NPO J 0402 G Assembly Pull EA 8
6 *R* 9LE 011234715107 C/M Multi. 470pF 50V NPO J 0402 G Assembly Pull EA 8
6 1 9LE 011134725116 C/M MULTI. 4700PF 50V X7R 0603 G Assembly Pull EA 2 C375,C377
6 *R* 9LE 011234725116 C/M Multi. 4700PF 50V X7R 0603 G Assembly Pull EA 2
6 1 9LE 011134731617 C/M Multi. 0.047uF 16V X7R K 0402 G Assembly Pull EA 4 C136,C379,C388,C460
6 *R* 9LE 011234731617 C/M Multi. 0.047uF 16V X7R K 0402 G Assembly Pull EA 4
6 *R* 9LE 011554731617 C/M Multi. 0.047uF 16V X7R K 0402 G Assembly Pull EA 4
6 1 9LE 011136815106 C/M MULTI 680PF 50V NPO 0603 G Assembly Pull EA 4 C338,C344,C372,C384
6 *R* 9LE 011236815106 C/M Multi. 680PF 50V NPO 0603 G Assembly Pull EA 4
6 *R* 9LE 011556815106 C/M MULTI 680PF 50V NPO 0603 G Assembly Pull EA 4
6 1 9LE 011138225117 C/M MULTI 8200PF 50V X7R 0402 G Assembly Pull EA 1 C188
6 *R* 9LE 011558225117 C/M MULTI 8200PF 50V X7R 0402 G Assembly Pull EA 1
6 *R* 9LE 011238225117 C/M MULTI 8200PF 50V X7R 0402 G Assembly Pull EA 1
6 1 9LE 011231051157 C/M Multi. 1.0uF 10V X5R 0402 G Assembly Pull EA 6 C103,C240,C249,C259,C304,C467
6 *R* 9LE 011551051157 C/M Multi. 1.0uF 10V X5R 0402 G Assembly Pull EA 6
6 *R* 9LE 011131051157 C/M Multi. 1.0uF 10V X5R 0402 G Assembly Pull EA 6
6 1 9LE 011231052556 C/M Multi. 1.0uF 25V X5R 0603 G Assembly Pull EA 9 C248,C306,C335,C348,C355,C382,C393,C413,C97
6 *R* 9LE 011131052556 C/M Multi. 1.0uF 25V X5R 0603 G Assembly Pull EA 9
6 *R* 9LE 011551052556 C/M Multi. 1.0uF 25V X5R 0603 G Assembly Pull EA 9
6 1 9LE 011231061115 C/M Multi. 10UF 10V X7R K 0805 G Assembly Pull EA 50
C114,C119,C120,C121,C149,C179,C186,C213,C215,C22,C222,C23,C23
0,C232,C233,C239,C242,C244,C246,C247,C250,C252,C258,C261,C262,
C294,C295,C302,C31,C322,C351,C357,C365,C370,C371,C374,C385,C4
0,C402,C432,C436,C464,C62,C66,C67,C76,C77,C93,C94,C96
6 *R* 9LE 011551061115 C/M Multi. 10UF 10V X7R K 0805 G Assembly Pull EA 50
6 1 9LE 011232251656 C/M MULTI 2.2UF 16V X5R K 0603 G Assembly Pull EA 2 C407,C410
6 *R* 9LE 011552251656 C/M MULTI 2.2UF 16V X5R K 0603 G Assembly Pull EA 2
6 *R* 9LE 011132251656 C/M MULTI 2.2uf 16V X5R 0603 G Assembly Pull EA 2
6 1 9LE 011232266085 C/M MULTI 22UF 6.3V X5R M 0805 L-F G Assembly Pull EA 5 C167,C169,C187,C214,C46
6 *R* 9LE 011552266085 C/M MULTI 22UF 6.3V X5R M 0805 L-F G Assembly Pull EA 5
6 1 9LE 011234756056 C/M MULTI 4.7uF 6.3V X5R K 0603 G Assembly Pull EA 2 C475,C480
6 *R* 9LE 011554756056 C/M MULTI 4.7uF 6.3V X5R K 0603 G Assembly Pull EA 2
6 *R* 9LE 011134756056 C/M MULTI 4.7uF 6.3V X5R K 0603 L-F G Assembly Pull EA 2
6 1 9LE 011521013290
C/M Multi 100pF 3.15KV U2J
1808_GRM42A7U3F101JW31L
G Assembly Pull EA 1 C453
6 *R* 9LE 011581013290
C/M Multi 100pF 3.2KV NPO J 1808?
(C1808N101J322T) LF
G Assembly Pull EA 1
