Level
Child P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
6 1 9LE 013000001654 RES. CF 0ohm 1/16W J 0402 G Assembly Pull EA 108
L39,L57,R113,R115,R122,R125,R132,R139,R149,R152,R156,R161,R167
,R196,R197,R202,R207,R208,R212,R223,R224,R225,R226,R227,R228,
R232,R233,R234,R235,R236,R237,R258,R259,R261,R267,R295,R301,R
304,R310,R318,R321,R335,R341,R343,R352,R355,R360,R363,R366,R3
70,R375,R378,R380,R384,R388,R391,R392,R393,R402,R403,R408,R40
9,R410,R411,R415,R416,R420,R425,R426,R432,R440,R441,R443,R447,
R449,R453,R458,R463,R464,R465,R467,R469,R471,R484,R486,R487,R
488,R489,R491,R495,R496,R497,R505,R506,R507,R508,R509,R545,R5
57,R568,R580,R586,R599,R600,R602,R68,R72,R813
6 1 9LE 013000001858 RES. CF 0.0ohm 1/8W J 0805 G Assembly Pull EA 11 L12,L13,L24,L27,L33,L34,L45,L48,L54,R353,R413
6 1 9LE 013010000055 RES. CF 100ohm 1/10W J 0603 G Assembly Pull EA 1 R562
6 1 9LE 013010001654 RES. CF 100ohm 1/16W J 0402 G Assembly Pull EA 76
R10,R100,R109,R11,R128,R129,R131,R133,R134,R136,R140,R142,R14
6,R153,R157,R158,R160,R165,R166,R168,R174,R175,R176,R178,R179,
R18,R180,R181,R182,R183,R184,R185,R186,R19,R20,R21,R22,R24,R2
5,R251,R26,R260,R27,R28,R29,R292,R294,R30,R306,R31,R313,R32,R3
46,R348,R39,R44,R460,R48,R51,R55,R553,R559,R581,R587,R6,R610,R
62,R69,R7,R70,R73,R77,R8,R81,R82,R9
6 1 9LE 013010011459 RES. CF 1.0Kohm 1/4W J 1206 G Assembly Pull EA 1 R231
6 1 9LE 013010011654 RES. CF 1Kohm 1/16W J 0402 G Assembly Pull EA 21
R145,R155,R272,R314,R315,R33,R350,R364,R369,R374,R414,R42,R42
8,R43,R446,R49,R537,R538,R54,R542,R575
6 1 9LE 013010021654 RES. CF 10Kohm 1/16W J 0402 G Assembly Pull EA 38
R116,R127,R130,R14,R141,R15,R200,R209,R243,R248,R275,R337,R34
4,R345,R35,R362,R368,R383,R4,R437,R50,R501,R503,R504,R521,R53
4,R551,R556,R569,R583,R590,R592,R601,R656,R657,R661,R662,R83
6 1 9LE 013010031654 RES. CF 100Kohm 1/16W J 0402 G Assembly Pull EA 3 R16,R17,R177
6 1 9LE 013010041654 RES. CF 1Mohm 1/16W J 0402 G Assembly Pull EA 3 R210,R385,R71
6 1 9LE 013010091654 RES. CF 10ohm 1/16W J 0402 G Assembly Pull EA 9 R118,R120,R173,R190,R302,R40,R482,R502,R511
6 1 9LE 013010091859 RES. CF 10ohm 1/8W J 1206 G Assembly Pull EA 1 R558
6 1 9LE 013012021654 RES. CF 12 Kohm 1/16W J 0402 G Assembly Pull EA 2 R584,R591
6 1 9LE 013018011654 RES. CF 1.8Kohm 1/16W J 0402 G Assembly Pull EA 5 R309,R34,R367,R431,R519
6 1 9LE 013020001654 RES. CF 200ohm 1/16W J 0402 G Assembly Pull EA 1 R452
6 11 9LE 013022031654 RES. CF 220Kohm 1/16W J 0402 G Assembly Pull EA 1 R204
6 1 9LE 013027091654 RES. CF 27ohm 1/16W J 0402 G Assembly Pull EA 1 R490
6 1 9LE 013033011654 RES. CF 3.3Kohm 1/16W J 0402 G Assembly Pull EA 4 R316,R372,R436,R526
6 1 9LE 013033081858 RES. CF 3.3ohm 1/8W J 0805 G Assembly Pull EA 4 R327,R365,R394,R417
6 1 9LE 013033090055 RES. CF 33ohm 1/10W J 0603 G Assembly Pull EA 4 R323,R358,R419,R442
6 1 9LE 013033091654 RES. CF 33ohm 1/16W J 0402 G Assembly Pull EA 32
R103,R105,R194,R214,R215,R216,R217,R218,R219,R300,R373,R376,R
390,R418,R439,R450,R475,R476,R493,R522,R525,R531,R533,R539,R5
40,R541,R546,R547,R548,R582,R588,R643
6 1 9LE 013039031654 RES. CF 390Kohm 1/16W J 0402 G Assembly Pull EA 2 R119,R59
6 1 9LE 013047000055 RES. CF 470ohm 1/10W J 0603 G Assembly Pull EA 4 R405,R412,R585,R594
6 1 9LE 013047011654 RES. CF 4.7Kohm 1/16W J 0402 G Assembly Pull EA 23
R164,R191,R192,R193,R198,R199,R206,R322,R45,R500,R514,R517,R5
43,R544,R550,R571,R579,R595,R74,R78,R805,R86,R87
6 1 9LE 013047021654 RES. CF 47Kohm 1/16W J 0402 G Assembly Pull EA 4 R356,R560,R593,R598
6 1 9LE 013068001654 RES. CF 680 ohm 1/16W J 0402 G Assembly Pull EA 1 R195
6 1 9LE 013068011654 RES. CF 6.8 Kohm 1/16W J 0402 G Assembly Pull EA 1 R1
6 1 9LE 013075090055 RES. CF 75ohm1/10W J 0603 G Assembly Pull EA 2 R567,R812
6 1 9LE 013110011614 RES. MF 1K ohm 1/16W F 0402 G Assembly Pull EA 20
R124,R126,R154,R162,R317,R319,R320,R324,R333,R336,R354,R357,R
429,R433,R451,R456,R60,R61,R91,R97
6 1 9LE 013110021614 RES. MF 10Kohm 1/16W F 0402 G Assembly Pull EA 2 R114,R47
6 1 9LE 013110031614 RES. MF 100Kohm 1/16W F 0402 G Assembly Pull EA 3 R66,R79,R80
6 1 9LE 013111001614 RES. MF 110ohm 1/16W F 0402 G Assembly Pull EA 2 R386,R513
