Level
Child P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
6 21 9LE 013114321614 RES. MF 14.3Kohm 1/16W F 0402 G Assembly Pull EA 1 R102
6 1 9LE 013115021614 RES. MF 15.0 K ohm 1/16W F 0402 G Assembly Pull EA 6 R13,R187,R2,R574,R578,R84
6 1 9LE 013115031614 RES. MF 150Kohm 1/16W F 0402 G Assembly Pull EA 3 R108,R159,R169
6 1 9LE 013118001614 RES. MF 180ohm 1/16W F 0402 G Assembly Pull EA 1 R512
6 1 9LE 013118021614 RES. MF 18kohm 1/16W F 0402 G Assembly Pull EA 4 R249,R282,R381,R64
6 1 9LE 013120021614 RES. MF 20Kohm 1/16W F 0402 G Assembly Pull EA 2 R117,R52
6 1 9LE 013122120015 RES. MF 22.1Kohm 1/10W F 0603 G Assembly Pull EA 1 R404
6 1 9LE 013123221614 RES. MF 23.2 Kohm 1/16W F 0402 G Assembly Pull EA 1 R37
6 1 9LE 013124001614 RES. MF 240ohm 1/16W F 0402 G Assembly Pull EA 11 R110,R121,R293,R311,R342,R371,R382,R462,R499,R53,R58
6 1 9LE 013124921614 RES. MF 24.9 Kohm 1/16W F 0402 G Assembly Pull EA 1 R170
6 1 9LE 013127421614 RES. MF 27.4 Kohm 1/16W F 0402 G Assembly Pull EA 3 R252,R268,R65
6 1 9LE 013131611614 RES. MF 3.16K ohm 1/16W F 0402 G Assembly Pull EA 1 R23
6 1 9LE 013133091614 RES. MF 33 ohm 1/16W F 0402 G Assembly Pull EA 6 R485,R492,R494,R498,R564,R565
6 1 9LE 013139021614 RES. MF 39Kohm 1/16W F 0402 G Assembly Pull EA 2 R576,R577
6 1 9LE 013143021614 RES. MF 43 Kohm 1/16W F 0402 G Assembly Pull EA 2 R572,R573
6 1 9LE 013147021614 RES. MF 47 Kohm 1/16W F 0402 G Assembly Pull EA 6 R283,R289,R307,R308,R98,R99
6 1 9LE 013149921614 RES. MF 49.9 Kohm 1/16W F 0402 G Assembly Pull EA 1 R106
6 1 9LE 013156091614 RES. MF 56ohm 1/16W F 0402 G Assembly Pull EA 6 R296,R297,R377,R379,R481,R483
6 1 9LE 013168011614 RES. MF 6.8 Kohm 1/16W F 0402 G Assembly Pull EA 2 R523,R535
6 1 9LE 013168021614 RES. MF 68Kohm 1/16W F 0402 G Assembly Pull EA 2 R104,R85
6 1 9LE 013182021614 RES. MF 82Kohm 1/16W F 0402 G Assembly Pull EA 1 R101
6 1 9LE 014100003853 ARRAY RES. A(X) 0ohm 4R J 8P 0402 G Assembly Pull EA 28
RP1,RP12,RP14,RP15,RP16,RP17,RP18,RP19,RP2,RP20,RP21,RP22,
RP23,RP24,RP25,RP26,RP27,RP28,RP3,RP31,RP32,RP33,RP34,RP4,
RP5,RP6,RP7,RP8
6 1 9LE 014110003853 ARRAY RES. A(X) 100ohm 4R J 8P (Size:0402) G Assembly Pull EA 6 RP10,RP11,RP13,RP29,RP30,RP9
6 1 9LE 030310023517
CONN B TO FPC 0.5mm 51P 90' SMD(196334-51041-
3) HF
G Assembly Pull EA 1 J5
6 *R* 9LE 030310023516
CONN B TO FPC 0.5mm 51P 90'
SMD(FBSNL05002N51) HF
G Assembly Pull EA 1
6 1 9LE 030410000510
CONN HDMI 19P 90' SMD WITH SPRING (1165-
2CG04-24P) HF
G Assembly Pull EA 4 P3,P4,P5,P6
6 1 9LE 035410000150 X'FMR LAN FILTER SMD 16PIN G Assembly Pull EA 1 U37
6 *R* 9LE 035410000190 X'FMR LAN 10/100Base-T (NS601683) SMD LF G Assembly Pull EA 1
6 1 9LE 036020100150 PWR IND 10uH 3.1A (MNR-8040-100M) LF G Assembly Pull EA 1 L4
6 *R* 9LE 036020100170 PWR IND. 10uH 3.2A(LVS808040L-100M-N) LF G Assembly Pull EA 1
6 1 9LE 036020159750
PWR IND. 1.5uH 10.5A 10x10x5mm(MSCDRI-105R-
1R5N) LF
G Assembly Pull EA 1 L22
6 1 9LE 036020229550 PWR IND. 2.2uH 4.8A (MNR-6045-2R2N-E) LF G Assembly Pull EA 5 L2,L23,L25,L3,L8
6 *R* 9LE 036023229520
PWR IND. 2.2uH? 5.1A 6x6x4.5mm (VLS6045EX-
2R2N) HF
G Assembly Pull EA 5
6 1 9LE 036021229120 PWR IND. 2.2uH 6.7A(VLP8040T-2R2N) LF G Assembly Pull EA 2 L11,L6
6 *R* 9LE 036020229170 PWR IND. 2.2uH 7.2A(LVS808040L-2R2M-N) LF G Assembly Pull EA 2
6 1 9LE 036023100520
PWR IND. 10uH 3.4A 6x6x4.5mm(VLS6045EX-100M)
G Assembly Pull EA 4 L37,L41,L51,L56
6 *R* 9LE 036020100270 PWR IND. 10uH 3.2A(LVS606045L-100M-N) LF G Assembly Pull EA 4
6 1 9LE 037000014252 BEAD 80ohm 6A 0805 GMLB-201209-0080P-N8B HF G Assembly Pull EA 36
L1,L10,L14,L15,L17,L18,L19,L26,L31,L36,L42,L43,L44,L46,L47,L49,L5,L5
0,L53,L58,L59,L60,L63,L64,L7,L9,R172,R189,R277,R303,R5,R88,R92,R
93,R94,R95
6 *R* 9LE 037000014282 CHIP BEAD 80ohm 6A 0805 (GB201212K800TM) LF G Assembly Pull EA 36
6 1 9LE 039050042343 GEN. DIODE LL4148WP (CD4148WP) SMD 1206 LF G Assembly Pull EA 3 D12,D2,D6
6 *R* 9LE 039050071293 DIODE FAST 0.3A 100V 1N4148W-7-F SOD-123 LF G Assembly Pull EA 3
6 1 9LE 039060050293 Schottky Diode 0.2A 30V BAT54C-7-F SOT-23 HF G Assembly Pull EA 3 D3,D7,D9
Confidential- do not copy
Page 14-9
File No. SG-0000361
