Level
Child P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
7 *R* 9LE 011231025117 C/M Multi. 1000PF 50V X7R 0402 G Assembly Pull EA 9
7 1 9LE 011131031617 C/M Multi. 0.01uF 16V X7R K 0402 G Assembly Pull EA 3 C496,C858,C860
7 *R* 9LE 011231031617 C/M Multi. 0.01uF 16V X7R K 0402 G Assembly Pull EA 3
7 *R* 9LE 011551031617 C/M Multi. 0.01uF 16V X7R 0402 (CL05B103KO5NNN) G Assembly Pull EA 3
7 1 9LE 011131041617 C/M Multi. 0.1uF 16V X7R 0402 G Assembly Pull EA 296
C100,C452,C497,C498,C499,C500,C501,C502,C503,C504,C505,C506,C
507,C508,C509,C510,C511,C512,C513,C515,C516,C517,C518,C519,C5
20,C521,C522,C523,C527,C528,C530,C532,C533,C534,C535,C536,C53
7,C538,C539,C540,C541,C542,C543,C544,C545,C546,C547,C548,C549,
C551,C552,C554,C555,C556,C557,C558,C559,C560,C561,C563,C564,C
565,C566,C567,C570,C571,C572,C573,C576,C577,C578,C581,C582,C5
85,C586,C594,C596,C597,C598,C599,C600,C601,C602,C603,C604,C60
5,C606,C607,C608,C609,C610,C611,C612,C613,C614,C615,C616,C618,
C619,C620,C621,C622,C623,C624,C625,C626,C627,C628,C629,C630,C
631,C632,C633,C635,C636,C637,C638,C639,C640,C641,C642,C643,C6
44,C645,C646,C647,C648,C649,C650,C651,C652,C653,C654,C655,C65
6,C657,C658,C659,C660,C661,C662,C663,C664,C665,C666,C667,C668,
C670,C672,C674,C675,C676,C677,C678,C680,C681,C682,C683,C684,C
685,C686,C689,C690,C692,C693,C694,C695,C697,C698,C699,C700,C7
02,C703,C704,C705,C706,C707,C708,C711,C712,C713,C714,C715,C71
6,C718,C719,C720,C721,C722,C723,C724,C725,C726,C728,C729,C730,
C731,C732,C733,C734,C736,C737,C738,C740,C742,C743,C744,C745,C
746,C747,C748,C749,C750,C752,C753,C754,C755,C756,C757,C758,C7
59,C760,C761,C762,C764,C765,C766,C767,C768,C769,C770,C772,C77
3,C775,C776,C777,C778,C779,C780,C781,C782,C783,C784,C786,C787,
C790,C791,C792,C793,C794,C795,C796,C800,C801,C802,C803,C804,C
805,C806,C807,C808,C809,C810,C811,C812,C813,C814,C815,C816,C8
17,C819,C820,C821,C822,C823,C825,C826,C827,C829,C831,C832,C84
2,C843,C844,C847,C849,C850,C851,C852,C853,C855,C856,C859,C861,
C863,C864
7 *R* 9LE 011231041617 C/M Multi. 0.1uF 16V X7R 0402 G Assembly Pull EA 296
7 *R* 9LE 011551041617
C/M Multi. 0.1uF 16V X7R K 0402
G Assembly Pull EA 296
7 1 9LE 011131042516 C/M Multi. 0.1uF 25V X7R 0603 G Assembly Pull EA 5 C679,C687,C688,C701,C727
7 *R* 9LE 011231042516 C/M Multi. 0.1uF 25V X7R 0603 G Assembly Pull EA 5
7 *R* 9LE 011551042516 C/M Multi. 0.1uF 25V X7R 0603 G Assembly Pull EA 5
7 1 9LE 011131051616 C/M MULTI 1.0uF 16V X7R K 0603 G Assembly Pull EA 5 C526,C529,C583,C590,C591
7 *R* 9LE 011231051616 C/M MULTI 1.0uF 16V X7R 0603 G Assembly Pull EA 5
7 *R* 9LE 011551051616 C/M MULTI 1.0uF 16V X7R K 0603 G Assembly Pull EA 5
7 1 9LE 011131215117 C/M MULTI 120PF 50V X7R K 0402 G Assembly Pull EA 1 C797
7 *R* 9LE 011551215117 C/M MULTI 120PF 50V X7R K 0402 G Assembly Pull EA 1
7 1 9LE 011134705106 C/M MULTI. 47PF 50V NPO 0603 G Assembly Pull EA 2 C862,C865
7 *R* 9LE 011234705106 C/M Multi. 47PF 50V NPO 0603 G Assembly Pull EA 2
7 1 9LE 011134715107 C/M Multi. 470pF 50V NPO J 0402 G Assembly Pull EA 1 C568
7 *R* 9LE 011234715107 C/M Multi. 470pF 50V NPO J 0402 G Assembly Pull EA 1
7 *R* 9LE 011554715107 C/M Multi. 470pF 50V NPO J 0402 G Assembly Pull EA 1
7 1 9LE 011134731617 C/M Multi. 0.047uF 16V X7R K 0402 G Assembly Pull EA 9 C833,C834,C835,C836,C837,C838,C839,C840,C848
7 *R* 9LE 011234731617 C/M Multi. 0.047uF 16V X7R K 0402 G Assembly Pull EA 9
7 *R* 9LE 011554731617 C/M Multi. 0.047uF 16V X7R K 0402 G Assembly Pull EA 9
7 1 9LE 011134741116 C/M MULTI 0.47uF 10V X7R 0603 G Assembly Pull EA 6 C735,C739,C741,C751,C763,C771
7 *R* 9LE 011234741116 C/M MULTI 0.47uF 10V X7R 0603 G Assembly Pull EA 6
7 1 9LE 011231051157 C/M Multi. 1.0uF 10V X5R 0402 G Assembly Pull EA 4 C774,C785,C857,C866
7 *R* 9LE 011551051157 C/M Multi. 1.0uF 10V X5R 0402 G Assembly Pull EA 4
7 *R* 9LE 011131051157 C/M Multi. 1.0uF 10V X5R 0402 G Assembly Pull EA 4
