Level
Child P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
7 1 9LE 011231061115 C/M Multi. 10UF 10V X7R K 0805 G Assembly Pull EA 27
C223,C514,C524,C525,C531,C553,C562,C569,C574,C575,C579,C580,C
584,C587,C592,C593,C669,C691,C696,C709,C717,C798,C818,C824,C8
30,C845,C846
7 *R* 9LE 011551061115 C/M Multi. 10UF 10V X7R K 0805 G Assembly Pull EA 27
7 1 9LE 011232266085 C/M MULTI 22UF 6.3V X5R M 0805 L-F G Assembly Pull EA 1 C224
7 *R* 9LE 011552266085 C/M MULTI 22UF 6.3V X5R M 0805 L-F G Assembly Pull EA 1
7 1 9LE 013000001654 RES. CF 0ohm 1/16W J 0402 G Assembly Pull EA 59
L61,L69,L70,L74,L76,L78,L81,L82,L83,L84,L85,L95,R604,R607,R613,R6
14,R621,R627,R629,R664,R672,R677,R681,R685,R691,R692,R693,R69
5,R697,R699,R701,R704,R709,R710,R711,R712,R714,R716,R718,R719,
R721,R729,R730,R733,R736,R739,R742,R750,R754,R755,R757,R758,R
759,R760,R761,R766,R800,R808,R809
7 1 9LE 013000001858 RES. CF 0.0ohm 1/8W J 0805 G Assembly Pull EA 5 L96,L97,R633,R641,R646
7 1 9LE 013010001654 RES. CF 100ohm 1/16W J 0402 G Assembly Pull EA 13
R674,R678,R680,R683,R688,R690,R694,R717,R720,R722,R725,R789,R
96
7 1 9LE 013010011654 RES. CF 1Kohm 1/16W J 0402 G Assembly Pull EA 4 R624,R673,R682,R732
7 1 9LE 013010021654 RES. CF 10Kohm 1/16W J 0402 G Assembly Pull EA 14
C673,R619,R626,R665,R666,R698,R700,R713,R715,R727,R765,R772,R
777,R782
7 1 9LE 013010091859 RES. CF 10ohm 1/8W J 1206 G Assembly Pull EA 1 R555
7 1 9LE 013022091654 RES. CF 22ohm 1/16W J 0402 G Assembly Pull EA 6 R676,R679,R702,R703,R734,R737
7 1 9LE 013030031654 RES. CF 300K ohm 1/16W J 0402 G Assembly Pull EA 1 R756
7 1 9LE 013033091654 RES. CF 33ohm 1/16W J 0402 G Assembly Pull EA 18
R253,R254,R648,R651,R652,R653,R741,R744,R748,R749,R762,R776,R
787,R788,R793,R797,R802,R803
7 1 9LE 013047011654 RES. CF 4.7Kohm 1/16W J 0402 G Assembly Pull EA 17
R518,R606,R615,R616,R620,R634,R638,R639,R645,R649,R650,R654,R
655,R707,R708,R785,R786
7 1 9LE 013047021654 RES. CF 47Kohm 1/16W J 0402 G Assembly Pull EA 12 R764,R767,R768,R769,R771,R773,R775,R778,R779,R780,R781,R795
7 1 9LE 013068091654 RES. CF 68 ohm 1/16W J 0402 G Assembly Pull EA 4 R743,R745,R746,R747
7 1 9LE 013075090055 RES. CF 75ohm1/10W J 0603 G Assembly Pull EA 2 R810,R811
7 1 9LE 013075091654 RES. CF 75ohm 1/16W J 0402 G Assembly Pull EA 4 R726,R751,R752,R753
7 1 9LE 013110011614 RES. MF 1K ohm 1/16W F 0402 G Assembly Pull EA 12 R667,R668,R671,R675,R686,R687,R705,R706,R738,R740,R770,R774
7 1 9LE 014100003853 ARRAY RES. A(X) 0ohm 4R J 8P 0402 G Assembly Pull EA 47
RP35,RP36,RP37,RP38,RP39,RP40,RP41,RP42,RP43,RP44,RP45,RP4
6,RP47,RP48,RP49,RP51,RP53,RP55,RP56,RP60,RP62,RP63,RP64,RP
65,RP66,RP68,RP69,RP70,RP71,RP72,RP73,RP74,RP75,RP76,RP77,R
P79,RP83,RP84,RP85,RP86,RP87,RP88,RP89,RP90,RP91,RP92,RP93
7 1 9LE 014110003853 ARRAY RES. A(X) 100ohm 4R J 8P (Size:0402) G Assembly Pull EA 12
RP50,RP52,RP54,RP57,RP58,RP59,RP61,RP67,RP78,RP80,RP81,RP8
7 11 9LE 017122725894 PCB MAIN BD 185*225*1.6t 4L (LC-65UB30U)(1:1) G Assembly Pull EA 1
7 1 9LE 037000014252 BEAD 80ohm 6A 0805 GMLB-201209-0080P-N8B HF G Assembly Pull EA 29
L21,L32,L65,L66,L67,L68,L71,L72,L73,L75,L77,L79,L80,L86,L87,L88,L89,
L91,L92,L93,R609,R611,R612,R630,R631,R632,R640,R642,R647
7 *R* 9LE 037000014282 CHIP BEAD 80ohm 6A 0805 (GB201212K800TM) LF G Assembly Pull EA 29
7 1 9LE 039060050293 Schottky Diode 0.2A 30V BAT54C-7-F SOT-23 HF G Assembly Pull EA 1 D18
7 *R* 9LE 039060110273 Schottky Diode 0.2A 30V BAT54C SOT-23 HF G Assembly Pull EA 1
7 1 9LE 040005415012 ZENER 5.49~5.73V UDZSTE-175.6B 1/5W SOD-323 G Assembly Pull EA 2 D20,D34
7 *R* 9LE 040005415717 ZENER 5.49~5.73V KDZ5.6VY 1/5W SOD-323 LF G Assembly Pull EA 2
7 1 9LE 041050005638 TR NPN 0.2A 40V LMBT3904LT1G SOT-23 HF G Assembly Pull EA 1 Q29
7 *R* 9LE 041050005643 TR NPN 0.2A 40V METR3904-G SOT-23 HF G Assembly Pull EA 1
7 1 9LE 043000016609 IC CMOS LOGIC 74HC4052PW TSSOP 16PIN LF G Assembly Pull EA 1 U40
7 *R* 9LE 043000038686
IC CMOS ANALOG U74HC4052G-P16-R TSSOP-16
G Assembly Pull EA 1
7 1 9LE 043030163045
IC SERIAL FLASH 32M MX25L3206EM2I-12G SOP-8
G Assembly Pull EA 1 U39
2 1 9LE 366500220189 IR BD ASS'Y SHARP LC-65UB30U M Assembly Pull EA 1
3 1 9LE 366500220189M IR BD ASS'Y SHARP LC-65UB30U MI P Phantom EA 1
4 11 9LE 045112500406 WAFER 1.25mm 4P 180' DIP KINK (M24014) L-F G Assembly Pull EA 1 JR1
Confidential- do not copy
Page 14-12
