Level
Child P/N
Seq
Specification UIT Supply Type UOM Qty Circuit Number
Child P/N
4 *R* 9LE 045112500401 WAFER 1.25mm 4P 180' KINK (53047-0410) L-F G EA 1
4 1 9LE 366500220189T IR BD ASS'Y SHARP LC-65UB30U TOP P Phantom EA 1
5 1 9LE 011131015117 C/M Multi. 100PF 50V X7R K 0402 G Assembly Pull EA 1 CR7
5 *R* 9LE 011231015117 C/M Multi. 100PF 50V X7R K 0402 G Assembly Pull EA 1
5 1 9LE 011131041617 C/M Multi. 0.1uF 16V X7R 0402 G Assembly Pull EA 2 CR5,CR6
5 *R* 9LE 011231041617 C/M Multi. 0.1uF 16V X7R 0402 G Assembly Pull EA 2
5 *R* 9LE 011551041617
C/M Multi. 0.1uF 16V X7R K 0402
G Assembly Pull EA 2
5 1 9LE 011231061155 C/M Multi. 10uF 10V X5R 0805 L-F G Assembly Pull EA 1 CR1
5 *R* 9LE 011551061155 C/M Multi. 10uF 10V X5R 0805 G Assembly Pull EA 1
5 1 9LE 013018001654 RES. CF 180ohm 1/16W J 0402 G Assembly Pull EA 1 RR1
5 1 9LE 013047091858 RES. CF 47ohm 1/8W J 0805 G Assembly Pull EA 1 LR1
5 21 9LE 017116711232 PCB IR BD FR4 77*8*1.6t 2L (LC-43UB30U)(1:10) G Assembly Pull EA 1
5 31 9LE 039080029473
DIODE TVS PROTECTOR 7pF AZ5125-01H.R7G
SOD-523 HF
G Assembly Pull EA 1 RVR1
5 1 9LE 044040000206
LED White TOP VIEW (LTW-C191UC5)
1.6*0.8*0.55mm SMD HF
G Assembly Pull EA 1 LED1
5 41 9LE 098002006060
IR RECEIVER 38KHz 4pin 5x4x2.5mm SMD(IRM-
H938T-TR2/LX) LF
G Assembly Pull EA 1 UR1
5 *R* 9LE 098002006051
IR RECEIVER 38KHz 4pin 5.2x4x2.8mm
SMD(NS6738S) LF
GEA1
2 1 9LE 366500320156 DISPLAY BD ASS'Y SHARP LC-65UB30U M Assembly Pull EA 1
3 1 9LE 366500320156T DISPLAY BD ASS'Y SHARP LC-65UB30U TOP P Phantom EA 1
4 1 9LE 011131041617 C/M Multi. 0.1uF 16V X7R 0402 G Assembly Pull EA 2 C2,C3
4 *R* 9LE 011231041617 C/M Multi. 0.1uF 16V X7R 0402 G Assembly Pull EA 2
4 *R* 9LE 011551041617
C/M Multi. 0.1uF 16V X7R K 0402
G Assembly Pull EA 2
4 1 9LE 011231052556 C/M Multi. 1.0uF 25V X5R 0603 G Assembly Pull EA 1 C1
4 *R* 9LE 011131052556 C/M Multi. 1.0uF 25V X5R 0603 G Assembly Pull EA 1
4 *R* 9LE 011551052556 C/M Multi. 1.0uF 25V X5R 0603 G Assembly Pull EA 1
4 1 9LE 013000001654 RES. CF 0ohm 1/16W J 0402 G Assembly Pull EA 3 R15,R16,R22
4 11 9LE 013110011614 RES. MF 1K ohm 1/16W F 0402 G Assembly Pull EA 1 R18
4 1 9LE 013120011614 RES. MF 2Kohm 1/16W F 0402 G Assembly Pull EA 8 R10,R19,R2,R20,R21,R3,R7,R9
4 41 9LE 017417703022
PCB DISPLAY BD CEM1 141*14*1.2t 1L(LC-
65UB30U)(1:10)
G Assembly Pull EA 1
4 31 9LE 022070206465
SW TACT 4.5*4.5*2.8mm 180' 260g? SMD
(SFKHRMA2231T) LF
G Assembly Pull EA 7 SW1,SW2,SW3,SW4,SW5,SW6,SW7
4 51 9LE 039080029473
DIODE TVS PROTECTOR 7pF AZ5125-01H.R7G
SOD-523 HF
G Assembly Pull EA 2 D1,D2
4 1 9LE 045112500496 WAFER 1.25mm 4P 90' SMD (MS24014R) L-F G Assembly Pull EA 1 J1
**** END ****
Confidential- do not copy
Page 14-13
File No. SG-0000361
