Sharp LL-S242A-W - Applying the Logo Sticker; Binding Cables; Video Cable and USB Cable

10
E
Binding Cables
Caution
• When connecting cables, spread a soft cloth on a stable level surface such as a desk, and gently place the monitor on it with
the screen facing down.
Video cable and USB cable
Secure the video cable (HDMI or DisplayPort) and USB cable using the cable clamp.
1. Remove the cable clamp.
Cable clamp
2. Route the cables through the cable
restraint slot.
Cable restraint
slot
3. Push the cable clamp down into
place.
Cable clamp
Applying the Logo Sticker
You can apply the supplied logo sticker to the unit.
Attach as shown in the following diagram, as required.
Power LED
Power LED
Landscape orientation Portrait orientation
