24
Adjusting the screen display (With analog connection)
MODE SELECT-2 Menu
MODE SELECT-2
INFORMATION
OFF TIMER
INPUT-2
1LINE 2LINES
INPUT-1 ANALOG
1600 x 1200 V:60Hz H:75.0kHz
Notes:
- To choose a menu option: / MODE button
- To complete adjustment: MENU button
INFORMATION
A model name (MODEL), a serial no. (S/N), and
usage time (USAGE TIME) of the monitor can be
checked.
After selecting [INFORMATION], press the
button. (Checking done: MENU button)
OFF TIMER
Power is automatically shut off when the set time
elapses.
After selecting [OFF TIMER], press the
button
and set [ON]/[OFF] by pressing the buttons.
If selecting [ON], press the / MODE button and
set the shut-off time by pressing the buttons.
(Between 1 and 23 hours may be set, by the hour.)
(Setting done: MENU button)
- When [ON] is selected, the remaining time is
displayed in the upper right of the screen during
the last 5 minutes before the shut-off. (The
remaining time is displayed for approx. 5
seconds, on each minute.)
- To clear automatic shut-off temporarily, press the
power button between the display of remaining
time and the shut-off of power.
To subsequently turn the power off, press the
power button again. (When next turning on
power, power is again automatically shut off
when the set time elapses.)
- If the monitor is turned on when the [OFF TIMER]
is set to [ON], the set time appears on the display
for several seconds. (If there is no input signal,
[NO SIGNAL] is displayed.)
INPUT-2
Set [1LINE] when connecting digital or analog
signal cables to a DVI-I input terminal (INPUT-2)
on the display.
Set [2LINES] when connecting a 2-input cable.
( buttons)
- If the connections and settings are not correctly
set, the screen will not be correctly displayed.
