Specifications
The analog RGB input connector pin
(Mini D-sub connector with 15 pins)
5 1234
10 6789
15 11121314
No. Function No. Function
1 TMDS data 2- 16 Hot plug detection
2 TMDS data 2+ 17 TMDS data 0-
3 TMDS data 2/4 shield 18 TMDS data 0+
4 N.C. 19 TMDS data 0/5 shield
5 N.C. 20 N.C.
6 DDC clock 21 N.C.
7 DDC data 22 TMDS clock shield
8 23 TMDS clock +
9 TMDS data 1- 24 TMDS clock -
10 TMDS data 1+ C1 Analog red image signal
11 TMDS data 1/3 shield C2 Analog green image signal
12 N.C. C3 Analog blue image signal
13 N.C. C4
14 +5V C5 Analog GND
15 GND
Analog vertically
synchronised signal
Analog horizontally
synchronised signal
Power management
The monitor is based on the VESA DPMS and the
DVI DMPM standards.
To activate the monitor's power management
function, both the video card and the computer
must conform to the VESA DPMS standard and the
DVI DMPM standard.
DPMS: Display Power Management Signalling
DMPM: Digital Monitor Power Management
DMPM mode Screen
Power
consumption
ON Display on 53 W
OFF Display off 4 W
DDC (Plug & Play)
This monitor supports the VESA DDC (Display
Data Channel) standard.
DDC is a signal standard for carrying out Plug &
Play functions on the monitor or PC. It transfers
information such as degree of resolution between
the monitor and PC. You can use this function if
your PC is DDC compliant and if it is set so that it
can detect the Plug & Play monitor.
There are many varieties of DDC due to the
differences between systems. This monitor works
with DDC2B.
The DVI-I input connector pin
(DVI-I connector with 29 pins)
1 765432 8
9 151413121110 16
17 23
22
21201918 24
C1
C2
C3
C4
C5
No. Function
1 Red video signal input
2 Green video signal input
3 Blue video signal input
4 GND
5 GND
6 For red video signal GND
7 For green video signal GND
8 For blue video signal GND
9 +5V
10 GND
11 GND
12 DDC data
13 For Hsync signal input
14 For Vsync signal input
15 DDC clock
DPMS mode Screen
Power
H-sync V-sync
consumption
ON Display on 53 W Yes Yes
STANDBY No Yes
SUSPEND Display off 4 W Yes No
OFF No No
