: B-ATT (focus) initial setting
: E-ATT (tracking) initial setting
: F-ATT (tracking) initial setting
Continued from
the preceding page
S B
SKIP UP SKIP DOWN
S E
SKIP UP SKIP DOWN
S F
SKIP UP SKIP DOWN
P-MODE
P-MODE
* When the "STOP" button is pressed in specific menu, the TEST MODE STOP state is set.
* In the specific setting display state the setting change digit changes when the [P-MODE] key is pressed.
(For RF side gain setting only one digit is provided. Therefore change does not occur.)
• 2-digit setting
1st digit (initial value) 2nd digit
• 3-digit setting
1st digit (initial value) 2nd digit 3rd digit
P-MODE
P-MODE
P-MODE
* In the specific setting display state the value of selected digit changes in the range of "0h to Fh" when the [VOL UP/DOWN] key is pressed.
However, the RF side gain setting changes in the range of "0h to 6h".
: Pre-Adjustment Value Check menu
: S gain "High" A signal offset measurement value (setting)
: S gain "High" B signal offset measurement value (setting)
: S gain "High" E signal offset measurement value (setting)
: S gain "High" F signal offset measurement value (setting)
: S gain "Low" A signal offset measurement value (setting)
: S gain "Low" B signal offset measurement value (setting)
: S gain "Low" E signal offset measurement value (setting)
: S gain "Low" F signal offset measurement value (setting)
: TCRS signal offset measurement value
: RF side pit section tracking gain setting
: RF side groove section tracking gain setting
: RF side TCR gain setting
: RF side focus gain setting
: Pit section adjustment COUT level setting
: Groove section adjustment COUT level setting
: A-ATT (focus) initial setting
PLAY
R S L T 1
Pre-Adjustment Value Check
A H
B H
SKIP UP SKIP DOWN
E H
SKIP UP SKIP DOWN
F H
SKIP UP SKIP DOWN
A L
SKIP UP SKIP DOWN
B L
SKIP UP SKIP DOWN
E L
SKIP UP SKIP DOWN
F L
SKIP UP SKIP DOWN
T H
SKIP UP SKIP DOWN
P T G
SKIP UP SKIP DOWN
G T G
SKIP UP SKIP DOWN
R C G
SKIP UP SKIP DOWN
R F G
SKIP UP SKIP DOWN
P C H
SKIP UP SKIP DOWN
G C H
SKIP UP SKIP DOWN
S A
SKIP UP SKIP DOWN
Continued to the
next page
SKIP UP SKIP DOWN
