PRICE
RANK
DESCRIPTIONNO.
PARTS CODE NO. PARTS CODE
PRICE
RANK
DESCRIPTION
MD-MT20/20C/20W
– 3 –
R826 VRS-CY1JB103J J AA 10 kohm,1/16W
R827 VRS-CY1JB304F J AF 300 kohms,1/16W
R828 VRS-CY1JB224F J AA 220 kohms,1/16W
R829 VRS-CY1JB333J J AA 33 kohms,1/16W
R831 VRS-CY1JB104J J AA 100 kohm,1/16W
R832 VRS-CY1JB106J J AA 10 Mohm,1/16W
R833 VRS-CY1JB470J J AA 47 ohms,1/16W
R851 VRS-CY1JB103J J AA 10 kohm,1/16W
R852 VRS-CY1JB473J J AA 47 kohms,1/16W
R853 VRS-CY1JB101J J AA 100 ohm,1/16W
R871 VRS-CY1JB103J J AA 10 kohm,1/16W
R878 VRS-CY1JB104J J AA 100 kohm,1/16W
R901,902 VRS-CY1JB1R0J J AA 1 ohm,1/16W
R903 VRS-CY1JB331J J AA 330 ohms,1/16W
R904 VRS-CY1JB333J J AA 33 kohms,1/16W
R905 VRS-CY1JB104J J AA 100 kohm,1/16W
R906 VRS-CY1JB274J J AA 270 kohms,1/16W
R907 VRS-CY1JB184J J AA 180 kohms,1/16W
R908 VRS-CY1JB104J J AA 100 kohm,1/16W
R909 VRS-CY1JB103J J AA 10 kohm,1/16W
R920 VRS-CY1JB104J J AA 100 kohm,1/16W
R921 VRS-CY1JB331J J AA 330 ohms,1/16W
R922 VRS-CY1JB104J J AA 100 kohm,1/16W
OTHER CIRCUITRY PARTS
CN101 QCNCW801XAFZZ J AH Socket,22Pin
CN451 QCNCW804NAFZZ J AE Socket,13Pin
CN482 QCNCW804JAFZZ J AE Socket,9Pin
CN601 QCNCW716RAFZZ J AF Socket,16Pin
CN701,702 QCNCWWQ33AFZZ J AE Socket,33Pin
! F871 QFS-L501AAFN0 J AG Fuse,T0.5A L 63V
J701 VHLGP1FB95R-1 J AP Jack,Optical/Line IN
J702 QJAKM0014AWZZ J AF Jack,Mic IN
J703 QJAKM0015AWZZ J AL Jack,Remote Control/
Headphones
J801 QJAKC0007AWZZ J AF Jack,DC IN
M901 RMOTV0524AFZZ J AS Motor Ass’y [Spindle]
M902 RMOTV0511AFZZ J AT Motor Ass’y [Sled]
M903 RMOTV0512AFM1 J AR Motor Ass’y [Head Up/Down]
PH901(8-3) VHPGP1S93K/-1 J AF Phote Interrupter,GP1S93K
SW401 QSW-M0172AFZZ J AD Switch,Push Type [Eject]
SW402 QSW-S0948AFZZ J AC Switch,Slide Type [Hold]
SW403 QSW-M0172AFZZ J AD Switch,Push Type
[Disc Lid Open]
SW801 QSW-M0006AWZZ J AD Switch,Push Type
[Ni-MH Battery Detection]
SW902(8-2) QSW-M0170AFZZ J AD Switch,Push Type [Disc Protect]
MECHANICAL PARTS
1 NGERH0597AFZZ J AC Wheel,Drive
2 NSFTD0334AFZZ J AD Screw,Drive
3 LHLDX3141AFM1 J AP Cartridge Holder Ass’y
4 MSPRT1625AFFJ J AD Spring,Eject Lever
5 LANGF1610AFZZ J AC Bracket,Cancel
6 LCHSM0944AFM1 J AT Main Chassis Ass’y
7 PCUSG0599AFZZ J AB Cushion,Mechanism
8 QPWBH0337AFM1 J AN Mechanism Flexible PWB Ass’y
8- 1 ———— — Mechanism Flexible PWB
(Not Replacement Item)
8- 2(SW902) QSW-M0170AFZZ J AD Switch,Push Type [Disc Protect]
8- 3(PH901) VHPGP1S93K/-1 J AF Phote Interrupter,GP1S93K
9 MSPRP0925AFZZ J Spring,Drive Screw
10 PCOVP1339AFZZ J AD Cover,Mechanism
11 MARMM0170AFM1 J AK Magnetic Field Block
12 NGERH0603AFZZ J AE Gear,Drive
! 13 RCTRH8175AFZZ J BM Optical Pickup Unit
[Except for U.S.A.]
! 13 RCTRH8175AF10 J BM Optical Pickup Unit [For U.S.A.]
14 MSPRP0922AFFJ J AD Spring,Drive Grip
15 MSPRP0923AFZZ J Spring,Thrust Plate
16 NSFTM0292AFFW J AC Shaft,Guide
17 MLEVF2641AFZZ J Lever,Eject
18 QPWBH0338AFZZ J AH Magnetic Head Flexible PWB
19 MLEVF2637AFM1 J AH Lift Working Lever Ass’y
20 MLEVF2638AFFW J AD Lever,Block
21 MLEVF2639AFFW J AD Lever,Lift Joint
22 MLEVF2640AFZZ J Lever,Lift
23 MSPRD1362AFFJ J AD Spring,Lift Lever
24 RCILH0112AFZZ J AM Magnetic Head
501 LX-BZ0804AFFF J AA Screw,ø1.4×2.2mm
502 LX-JZ0154AFZZ J AA Screw,ø1.4×2.8mm
503 LX-BZ0823AFZZ J AA Screw,ø1.4×1.2mm
504 LX-WZ9290AFZZ J AA Washer,ø0.8×ø2.4×0.2mm
505 LX-BZ0800AFZZ J AA Screw,ø1.4×2.5mm
506 XSPSN14P01500 J AA Screw,ø1.7×2.5mm
507 LX-JZ0148AFZZ J AA Screw,ø1.7×3mm
508 XWSSD14-05000 J AA Washer,ø1.4×0.5mm
509 LX-BZ0959AFZZ J AB Screw,ø1.4×1.8mm
510 LX-WZ9296AFZZ J AA Washer,ø1.5×ø3.5×0.25mm
511 LX-BZ0974AFZZ J AB Screw,ø1.4×5.5mm
512 LX-BZ0991AFZZ J AB Screw,ø1.2×1.6mm
M901 RMOTV0524AFZZ J AS Motor Ass’y [Spindle]
M902 RMOTV0511AFZZ J AT Motor Ass’y [Sled]
M903 RMOTV0512AFM1 J AR Motor Ass’y [Head Up/Down]
CABINET PARTS
201 GFTAT3004AWM1 J AW Top Cabinet Ass’y
[MD-MT20-S/20C-S/20W-S]
201 GFTAT3004AWM2 J AW Top Cabinet Ass’y
[MD-MT20W-BL]
201 GFTAT3004AWM3 J AW Top Cabinet Ass’y
[MD-MT20W-GL]
201- 1 ———— — Top Cabinet
(Not Replacement Item)
201- 2 ———— — Bracket,Top Cabinet
(Not Replacement Item)
202 HDECQ0480AWM1 J AM Decoration Plate Ass’y
202- 1 ———— — Plate,Decoration
(Not Replacement Item)
202- 2 PSHEZ0033AWZZ J AD Sheet,Decoration Plate
203 TCAUS0044AWZZ J AB Label A,Class 3B
[MD-MT20W Only]
204 PSHEZ0035AWZZ J AB Sheet A,Operation Button
205 PSHEZ0036AWZZ J AB Sheet B,Operation Button
206 PSHEZ0037AWZZ J AC Sheet C,Operation Button
207 JKNBZ0623AWSA J AM Button,Operation
208 LANGT0058AWFW J AG Bracket,Operation Button
209 MSPRP0026AWFW J AB Spring A,Cartridge
210 MSPRP0027AWFW J AC Spring B,Cartridge
211 MSPRP0028AWFW J AB Spring C,Cartridge
212 TCAUS0043AWZZ J AC Label B,Class 3B
[MD-MT20W Only]
213 RUNTK0005AWZZ J AV Key Switch Flexible PWB Ass’y
214 RUNTZ0015AWZZ J BD LCD Ass’y
215 PSHEZ0046AWZZ J AB Sheet E,LCD
216 PSHEZ0044AWZZ J AB Sheet C,LCD
217 PCUSZ0016AWZZ J AB Cushion,Mechanism,Top
218 PSHEZ0045AWZZ J AB Sheet D,LCD
219 PCUSZ0017AWZZ J AB Cushion,Cartridge
220 GFTAU3008AWSA J AS Bottom Cabinet [MD-MT20-S]
220 GFTAU3009AWSA J AS Bottom Cabinet [MD-MT20C-S]
220 GFTAU3010AWSA J AS Bottom Cabinet [MD-MT20W-S]
220 GFTAU3011AWSA J AS Bottom Cabinet [MD-MT20W-BL]
220 GFTAU3012AWSA J AS Bottom Cabinet
[MD-MT20W-GL]
221 JKNBZ0625AWSA J AD Button,Hold
222 GCOVA1241AWSA J AC Cover,DC IN Jack
223 PSHET0014AWZZ J AE Sheet,Bottom Cabinet
224 PSHEZ0043AWZZ J AB Insulate Fiber,
Bottom Cabinet Sheet
225 LHLDZ3010AWM1 J AW Main Frame Ass’y
226 PCUSZ0015AWZZ J AB Cushion,Mechanism,Front
227 PCUSZ0014AWZZ J AB Cushion,Mechanism,Right
228 PCUSG0534AFZZ J AC Rubber,Preventive Vibration
229 PCUSG0641AFSA J AB Insulator
230 PSHET0015AWZZ J AB Sheet B,Insulator
231 PSHET0016AWZZ J AC Sheet C,Insulator
232 PCOVW1009AW00 J AC Cover,Battery Terminal,-
233 QTANB9018AWFQ J AD Terminal,Battery,-
234 PCOVW1008AW00 J AC Cover,Battery Terminal,+
235 QTANB9017AWFQ J AD Terminal,Battery,+
236 PGIDM0027AW00 J AC Guide,Battery
237 QTANB9016AWFQ J AD Terminal,Battery,+/-
238 LHLDZ1231AW00 J AC Holder,Battery Terminal,+/-
239 MLEVP0094AW00 J AC Lever,Battery Push
240 JKNBZ0624AWSA J AF Lever,Open
241 GCABA1185AWSA J AF Front Cabinet
[Except for MD-MT20W-BL]
241 GCABA1185AWSB J AF Front Cabinet [MD-MT20W-BL]
242 GCABB1185AWSA J AE Rear Cabinet
[Except for MD-MT20W-BL]
242 GCABB1185AWSB J AE Rear Cabinet [MD-MT20W-BL]
To Next Page
