NO.
PRICE
RANK
DESCRIPTIONPARTS CODE
NO. PARTS CODE
PRICE
RANK
DESCRIPTION
MD-MT20/20C/20W
– 4 –
243 QCNWN1478AWZZ J AG Flat Cable,33Pin
244 PSHEF0019AWZZ J AB Felt,Mechanism Flexible PWB
245 GDORB0001AWSA J AE Door,Battery [MD-MT20-S/
20C-S/20W-S]
245 GDORB0001AWSB J AE Door,Battery [MD-MT20W-BL]
245 GDORB0001AWSC J AE Door,Battery [MD-MT20W-GL]
246 PCUSZ0012AWZZ J AB Cushion,Vub
247 PSHEZ0047AWZZ J Insulate Fiber B
601 LX-BZ0045AWF3 J Screw,ø1.4×2mm
602 LX-BZ0805AFFN J AB Screw,ø1.7×2.5mm
603 LX-BZ0045AWFN J Screw,ø1.4×2mm
ACCESSORIES/PACKING PARTS (MD-MT20C/20W)
QCNWG0382AFZZ J AK Connecting Cord,RCA Type
QCNWG0422AFZZ J AQ Optical Digital Cable
RADPA3040AWZZ J AX AC Adaptor [MD-MT20C]
RADPA5402AFZZ J BF AC Adapter [MD-MT20W Except
for Taiwan/Australia/
New Zealand/Hong Kong]
RADPA5403AFZZ J BF AC Adaptor
[MD-MT20W for Taiwan]
RADPA6435AFZZ J BG AC Adaptor [MD-MT20W for
Australia/New Zealand]
RADPA8493AFZZ J BH AC Adaptor [MD-MT20W for
Hong Kong]
RPHOH0003AWZZ J AZ Headphones [MD-MT20C Only]
RPHOH0176AFZZ J AR Earphones [MD-MT20W Only]
RRMCW0001AWSA J AZ Remote Control
SPAKA0219AWZZ J AC Packing Add.,Unit [MD-MT20W]
SPAKA0220AWZZ J AC Packing Add.,Unit [MD-MT20C]
SPAKC0810AWZZ J AG Packing Case [MD-MT20W-S]
SPAKC0811AWZZ J AG Packing Case [MD-MT20C]
SPAKC0825AWZZ J AG Packing Case [MD-MT20W-BL]
SPAKC0829AWZZ J AG Packing Case [MD-MT20W-GL]
SPAKZ0485AWZZ J AD Pad,AC Adaptor [MD-MT20C]
SPAKZ0486AWZZ J AD Pad,AC Adaptor [MD-MT20W
Except for Australia/
New Zealand]
SPAKZ0487AWZZ J AD Pad,AC Adaptor [MD-MT20W for
Australia/New Zealand]
SPAKZ0490AWZZ J AC Pad,Operation Manual
[MD-MT20W for Australia/
New Zealand Only]
SPAKZ0518AWZZ J AB Sheet,Protect
SPAKZ0522AWZZ J AC Cushion,Protect
TCAUA0040AWZZ J AB Card,Taiwan Caution
[MD-MT20W for Taiwan Only]
TCAUH0050AWZZ J AB Caution,Headphones
[MD-MT20C Only]
TGANZ0022AW20 J AE Card,Taiwan Guarntee [MD-
MT20W-BL for Taiwan Only]
TGANZ0022AW21 J AE Card,Taiwan Guarntee [MD-
MT20W-GL for Taiwan Only]
TGANZ0022AW32 J Card,Taiwan Guarntee [MD-
MT20W-S for Taiwan Only]
TINSE0253AWZZ J AE Operation Manual [MD-MT20W
for Australia/New Zealand]
TINSK0093AWZZ J AG Operation Manual [MD-MT20C]
TINSZ0431AWZZ J AG Operation Manual [MD-MT20W
Except for Australia/
New Zealand]
TLABE0304AWZZ J AB Label,Bar Code [MD-MT20W-S
for Australia/New Zealand/
Taiwan Only]
TLABE0305AWZZ J AB Label,Bar Code [MD-MT20W-GL
for Australia/New Zealand/
Taiwan Only]
TLABE0306AWZZ J AB Label,Bar Code [MD-MT20W-BL
for Australia/New Zealand/
Taiwan Only]
TLABG0002AWZZ J AB Label,Hong Kong [MD-MT20W
for Hong Kong Only]
TLABH0055AWZZ J AF Sheet,E/C Comparision [MD-
MT20W for Taiwan Only]
TLABJ0009AWSA J AB Label,SHARP Corpration Japan
[MD-MT20W for Chile/Peru/
Bolivia Only]
TLABJ0010AWZZ J AB Label,Japan [MD-MT20W for
Chile/Peru/Bolivia Only]
TLABN0088AWZZ J AB Label,SER No. [Except for
Taiwan of MD-MT20W]
TLABN0092AWZZ J AB Label,SER No. [MD-MT20C/20W
for New Zealand]
TLABN0092AW02 J AB Label,SER No. [MD-MT20W
Except for Asia/Middle and
Near East/Africa/Australia/
New Zealand/Hong Kong]
TLABN0094AWZZ J AB Label,Taiwan SER.No. [MD-
MT20W for Taiwan Only]
TLABRF232AWZZ J AB Label,Bar Code [MD-MT20C]
TLABR1054AWZZ J AB Label,Bar Code [MD-MT20W-S
for Central South America/
Brazil/Chile/Peru/Bolivia Only]
TLABR1055AWZZ J AB Label,Bar Code [MD-MT20W-BL
for Central South America/
Brazil/Chile/Peru/Bolivia Only]
TLABR1056AWZZ J AB Label,Bar Code [MD-MT20W-GL
for Central South America/
Brazil/Chile/Peru/Bolivia Only]
TLABS0225AWZZ J AB Label,CPA [MD-MT20W for Asia/
Middle and Near East/Africa
Only]
TLABZ0589AWZZ J AB Label,Taiwan Impoter [MD-
MT20W-S for Taiwan Only]
TLABZ0590AWZZ J AB Label,Taiwan Impoter [MD-
MT20W-BL for Taiwan Only]
TLABZ0591AWZZ J AB Label,Taiwan Impoter [MD-
MT20W-GL for Taiwan Only]
TLABZ0600AWSA J AC Label,Made in Malaysia [MD-
MT20W for Australia/
New Zealand/Brazil Only]
TLABZ0618AWZZ J AB Label,Made in Malaysia [MD-
MT20W for Australia/New
Zealand/Taiwan/Brazil Only]
TLSTS0011AWZZ J AB Taiwan SS List
[MD-MT20W for Taiwan Only]
TSPC-0574AWZZ J AC Label,Taiwan Specifications
[MD-MT20W-S for Taiwan
Only]
TSPC-0576AWZZ J AC Label,Taiwan Specification [MD-
MT20W-BL for Taiwan Only]
TSPC-0577AWZZ J AC Label,Taiwan Specifications
[MD-MT20W-GL for Taiwan
Only]
UBAGC0001AWZZ J AK Battery Carrying Case
UBAGC0002AWSA J AK Carrying Case
UBATM0002AWSA J BC Battery,Rechargeable Nickel-
Metal Hydride
92LG-CARD1266E J AB Gurantee Card [MD-MT20W for
Australia/New Zealand Only]
92LPLUG155A J AG Adaptor,AC Plug [MD-MT20W
for Middle South America/
Brazil/Chile/Peru/Bolivia Only]
ACCESSORIES (MD-MT20)
QCNWG0382AFZZ J AK Connecting Cord,RCA Type
QCNWG0422AFZZ J AQ Optical Digital Cable
RADPA3040AWZZ J AX AC Adaptor [MD-MT20]
RPHOH0003AWZZ J AZ Headphones [MD-MT20]
RRMCW0001AWSA J AZ Remote Control
TCAUH0050AWZZ J AB Caution,Headphones
[MD-MT20 Only]
TINSE0254AWZZ J AE Operation Manual [MD-MT20]
TINSZ0429AWZZ J AB Quick Guide [MD-MT20 Only]
UBAGC0001AWZZ J AK Battery Carrying Case
UBAGC0002AWSA J AK Carrying Case
UBATM0002AWSA J BC Battery,Rechargeable Nickel-
Metal Hydride
P.W.B. ASSEMBLY (Not Replacement Item)
PWB-A1,2 92LPWB3107MDSS J — Main,Audio (Combined Ass’y)
OTHER SERVICE PARTS
UDSKM0001AFZZ J AZ Recording Mini Disc
88GMMD-110 J BV High Reflection Disc MMD-110
(TEAC Test MD)
88GMMD-212 J BU Low Reflection Disc MMD-212
(TEAC Test MD)
88GMMD-213A J Low Reflection Disc MMD-213A
(TEAC Test MD)
