44
■ Connecting external units
The other MD/CD player
Commercially available lead
with 3.5 mm (1/8") stereo
mini-plug and RCA plugs
To the output/
headphone socket
RIGHT
LEFT
To the analogue
output sockets
LEFT
RIGHT
RIGHT
LEFT
● Red plug → To RIGHT
● White plug → To LEFT
Commercially available RCA lead
■ Headphones
Notes:
● Before plugging in or unplugging the headphones, make sure the volume level is reduced.
● Be sure your headphones have a 3.5mm (1/8") diameter plug and are between 16 ohms and 50 ohms impedance.
The recommended impedance is 32 ohms.
● When headphones are connected, the speakers are disabled automatically.
Adjust the VOLUME control for the desired volume.
USING EXTERNAL UNITS
Before connecting external units, set this unit to the stand-by mode and turn off the power to the external units.
*44-46 00.1.13, 0:02 PM44
