MD-S301/S301W
– 3 –
NAME OF PARTS
Main unit
1. Volume Buttons: +, –
2. Stop/Power Off/Charge Button:
:OFF
3. Power Indicator
4. Fast Reverse Button:
5. Play/Fast Forward Button:
6. 5V DC Input Socket
7. Eject Lever
8. Hold Switch
9. Battery Case Connection Terminals
10. Headphones Socket
11. Rechargeable Lithium-lon Battery Compartment
Remote control unit
1. Character/Time Information Display
2. Disc Mode Indicator
3. Total Track Number Display
4. Track Number Indicator
5. Battery Indicator:
6. Repeat Indicator:
7. Random Indicator
8. Headphones Socket
9. Hold Switch
10. Play Mode Button
11. Volume Buttons: +, –
12. Bass Button
13. Display Button
14. Play/Pause Button:
15. Stop/Power Off Button:
16. Fast Reverse/Fast Foward Buttons:
1
2
3
4
5
6
7
10
11
8
9
RANDOM
TOTAL
1
10
11
12
9
13
14
15
16
8
1
2
6
7
4
5
3
BATTERY DISPOSAL (MD-S301 ONLY)
Contains nickel cadmium (or sealed lead) battery. Must be
recycled or disposed of properly. Remove the battery from the
product and contact federal or state environmental agencies
for information on recycling and disposal options.
