Rechargeable battery power
When the rechargeable battery is used for
the first time or when you want to use it
after a long period of disuse, be sure to
charge it fully.
1
Open the rechargeable battery com-
partment cover.
2
Insert the rechargeable battery.
Insert the side with the arrow first.
3
Close the rechargeable battery com-
partment cover.
4
Plug the AC adaptor into the AC outlet,
and then insert the plug on the AC
adaptor cord into the DC IN 5V jack.
5
Press the :OFF button to begin charg-
ing.
The POWER indicator will flash, and
the battery will begin charging.
Battery charging will be complete in 3
hours. When the battery is fully
charged, the POWER indicator will go
out.
1
2
POWER SOURCE
Notes:
After charging is complete, the AC
adaptor may be left connected.
(For example, when charging at night)
The battery will not be charged when-
ever the power to the main unit is
turned on.
If the operation in step 5 is performed
without inserting the rechargeable bat-
tery, the POWER indicator will flash for
5 seconds. This is normal.
Do not force open the rechargeable
battery cover too far.
Do not attach the optionally available
battery case when charging the internal
battery.
This unit can be used with 4 different power sources: a rechargeable battery, an AC
adaptor, an optionally available battery case (AD-S30BC), and an optionally available car
adaptor (AD-CA20X).
OPEN
OPEN
Mark
To the
DC IN 5V
jack
AC 120V, 60 Hz
OPEN
OFF
POWER
5
Insert
securely,
all the way
in.
4
Checking the remaining
amount of battery charge
The remaining amount of battery charge is
shown by the battery indicator ( ) on
the remote control display during oper-
ation.
How to read the battery indicator
When the battery is completely dis-
charged, the whole battery indicator will
flash. Recharge the battery or replace
the alkaline battery with a new one.
When the battery has completely run
out, “Lo BATT” will appear in the dis-
play. Then, the power will be discon-
nected automatically.
Notes:
When the AC adaptor included with this
unit or an optionally available car adaptor
is used, the battery indicator will not be
shown.
The number of bars shown in the battery
indicator may increase or decrease, de-
pending on the operation being per-
formed. This is normal.
When the rechargeable battery and the
alkaline battery are used at the same time,
the rechargeable battery is used first, and
then the alkaline battery.
Since the battery indicator shows the re-
maining amount of the particular battery
being used, the number of bars will in-
crease when the unit switches to the al-
kaline battery.
CONVENIENT OPERATION OF THE UNIT
Battery
indicator
Charging is
needed.
When the battery is
completely charged
