Sharp MX-2300 G

MX-2300G/N, MX-2700G/N 1 – 11
J. Tray setup
(1) Simulation setup
This is used to specify the paper type, paper size, and functions
used for each paper tray.
1) Press the [SYSTEM SETTINGS] key.
2) Touch the [Paper Tray Settings] key.
3) Touch the [Tray Settings] key.
4) Select the tray that you wish to configure.
(1) If needed, use the [p] [n] keys to switch through the trays.
(2) Touch the [Type/Size] key.
5) Touch the desired paper type.
Example: Tray 1 is selected
6) Select the paper size.
(1) Touch the desired paper size.
(2) Touch the [OK] key.
(2) Tray size setup
1) Pull out the paper tray.
Gently pull the tray out until it stops.
If paper remains in the tray, remove it.
2) Adjust the guide plates A and B by squeezing their lock levers
and sliding them to match the vertical and horizontal dimen-
sions of the paper to be loaded.
The guide plates A and B are slidable. Slide each guide plate
while squeezing its lock lever.
SYSTEM
SETTINGS
System Settings
Admin Password
Default Settings
Total Count
Address Control
Exit
List Print
(User)
Fax Data
Receive/Forward
USB-Device Check
Paper Tray
Settings
Printer Condition
Settings
Document Filing
Control
System Settings
Paper Tray Settings
OK
Tray Settings
Paper Type Registration
Auto Tray Switching
System Settings
Paper Tray Settings
Type / Size
Tray 1
Fixed Paper Side
Disable Duplex
Disable Staple
Disable Punch
OK
1/6
Print Copy Fax
I-Fax
Doc.
Filing
Plain / A4
(1)(2)
System Settings
Tray 1 Type/Size Setting
Select the paper type.
Plain Letter Head
Pre-Printed Pre-Punched
Recycled Colour
Cancel
1/2
1/2
System Settings
Select the paper type.
User Type 1 User Type 2
User Type 5 User Type 6 User Type 7
User Type 3 User Type 4
2/2
1/2
Tray 1 Type/Size Setting
Cancel
System Settings
Type
Plain
Type OK
A3 A4 A4R
A5R
B5R
B4
216x330(8 x13)
B5
1/3
2/2
Tray 1 Type/Size Setting
Size
1
/
2
(2)(1)
System Settings
Tray 1 Type/Size Setting
Type Size
Plain
Type OK
11x17
2/3
2/2
8 x11
1
/
2
8 x14
1
/
2
7x10R
1
/
4
8x11
1
/
2
5x8R
1
/
2
1
/
2
1
/
2
(2)(1)
System Settings
Type
Plain
Type OK
8K 16K 16KR
3/3
2/2
Tray 1 Type/Size Setting
Size
(2)(1)
B
A
