SHARP
MAINTENANCE
15
MX-2610N
MX-3110N
MX-3610N
Description
100K
120K
Maintenance Schedule A:
Process Section:
In addition to Black Consumable schedule (and/or colour schedule if indicated):-
Replace PTC unit (MX-230CU).
Replace Waste Toner Container (MX-230HB).
Replace Ozone Filter Kit (MX-C31FL).
Sim 24-04 Clear PTC Counter.
Sim 24-04 Clear Ozone Filter Counter.
Paper Feed & Transport:
Replace Paper Dust Removal Unit (MX-230PD).
Check/Clean all Paper Path Sensors (including Duplex unit).
Check/Clean/Replace PF Rollers (check tray counter using Sim 22-09).
Sim 24-04 Clear PS Paper Counter.
Fuser Section:
x
Replace Cleaning Roller Kit (MX-230CR).
x
Replace Web Cleaning Kit (MX-360WB) [MX-3610N only].
Check & Clean Upper and Lower Thermistors.
Check & Clean Fuser Separator Pawls.
x
Sim 24-04 Clear Fusing Belt Counter.
Clear Separation Clean Roller.
x
Sim 24-04 Fusing Web Counter.
Transfer Section:
Replace Primary (Image) Transfer Belt Kit (MX-230B1).
Replace Primary Transfer Cleaning Blade Kit (MX-230TL).
Clean ID & Registration Sensors.
Sim 24-04 Clear TC1 Belt Counter.
Clear Trans Blade Counter.
Sim 50-22 Drum Position & Registration Adjustment - select ALL.
General:
Clean all optics, CCD, and white reference plate.
Clean all RSPF sensors.
200K
240k
Maintenance Schedule B:
In addition to Maintenance Schedule A, perform the following:-
Fuser Section:
Replace Fusing Belt Kit (MX-361FB) [MX-3610N only].
Replace Fuser Pressure Roller Kit (MX-230LH).
Sim 24-04 Clear Fusing Belt Counter.
Sim 24-04 Clear Fusing Roller Counter.
Clear Press Roller Counter.
