Sharp MX-3640N Technical Guide

TEST SIMULATION
SHARP
50
55
MFP Data Setting
3
Controller soft switch setting:-
SW29-7
Disable Pop Up Message for Data
is being cleared (DSK) & Settings
of machine changed by Web
page:-
0 = Displayed (Default)
1 = Not displayed
SW30-3
Hold Image Send destination
address function.
0 = Disabled,
1 = Enabled (Default)
SW33-4
90 degrees rotate from the
Bypass Tray when Size Input is
set to "X=148 / Y=210
0 = Disabled, 1 = Enabled
10
Special Stamp setting (Taiwan only)
56
MFP Data Import & Export
1
Transfer data execute (MFP/SD Card/SRAM
& EEPROM)
2
Export/Import EEPROM/SD Card/HDD data
3
Document filing data backup to USB
4
Job log data backup to USB
5
Export Adjustment & Settings data to USB
6
Output Jam/Trouble data
7
Export Syslog data to USB
60
Memory Operation & Test
1
SDRAM read/write test (MFP PWB)
61
LSU Writing Adjustment/Test
1
LSU test (Polygon & BD detection check)
3
LSU power auto setup
4
LSU position adjustment (CMYK)
11
LSU power correction (automatic)
12
LSU power manual correction
13
LSU power correction value reset/clear
62
HDD Operation & Test
1
HDD/SD Card format
2
HDD partial read/write check
3
HDD read/write check (all areas)
6
Smart (HDD) self diagnostic test
7
Smart (HDD) self diagnostic error log
8
HDD/SD Card format (excluding system &
operation manual area)
10
Job completion list deletion (with job log)
62
HDD Operation & Test
11
Document filing data deletion
12
Enable/disable auto format for HDD
trouble.
13
HDD format (manual area only)
14
Delete document filing management data
20
Check operation of mirroring hard disk
63
CCD Operation & Adjustment
1
Shading correction data display
2
Shading correction execution (force)
3
CCD gamma & colour correction adjust.
4
SIT chart patch density list display
5
CCD gamma & colour correction reset.
6
Print engine colour balance
7
Standard target colour calibration set-up
8
Standard scanner target reset (Service)
11
Colour Balance setting (Factory Mode).
64
Self Test Print
1
Test print (Colour mode)
2
Test print (B/W mode)
4
Printer self print test
5
Printer self print test (PCL)
6
Printer self pint test (PS)
7
Adjustment pattern print (Sim46-21)
65
LCD Operation & Adjustment
1
LCD touch panel adjustment
2
LCD touch panel adjustment result display
5
Operation panel key input test
66
Fax Control Settings & Adjustments
1
Fax Soft SW setting:-
SW24
Communication Signal sending
level (bits 1-8):-
Default Value (Australia/NZ)
00001011
SW27-4
V.34 mode function (call
arrival):-
0 = V.34 valid.
1 = V.34 invalid.
SW27-5
V.34 mode function (polling
when calling):-
0 = V.34 valid.
1 = V.34 invalid.

Sharp MX-3640N Specifications

General

Print Speed	36 ppm
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	36 ppm
Scan Resolution	600 x 600 dpi
Fax Speed	33.6 kbps
Copy Speed (Black)	36 cpm
Copy Resolution	600 x 600 dpi
Connectivity	USB 2.0, Ethernet
Paper Size	Up to 12" x 18"
Network Connectivity	10/100/1000 Base-T
Operating System Compatibility	Windows, Mac, Linux
Display	7-inch color touchscreen
