Sharp MX-3640N Technical Guide

SHARP
TROUBLE CODES
53
F1
08
Finisher staple shift motor trouble.
10
Finisher staple operation trouble.
11
Finisher grip operation trouble.
15
Finisher exit tray lift operation trouble.
19
Finisher alignment operation trouble F.
20
Finisher alignment operation trouble R
21
Finisher interface fan motor trouble.
31
Saddle Finisher folding sensor trouble.
32
Finisher/Punch unit communication error.
33
Punch unit shift operation trouble.
34
Punch operation trouble.
36
Punch paper edge detection error
37
Finisher data backup RAM error.
38
Punch data backup RAM trouble.
39
Punch paper dust sensor trouble.
41
Saddle paper positioning trouble
43
Saddle alignment operation trouble.
45
Saddle staple trouble.
47
Saddle paper transport motor trouble.
50
Finisher incompatibility trouble.
F2
22
Discharge lamp trouble (K)
23
Discharge lamp trouble (C)
24
Discharge lamp trouble (M)
25
Discharge lamp trouble (Y)
39
Process temperature sensor trouble
40
Toner density sensor trouble (K)
41
Toner density sensor trouble (C)
42
Toner density sensor trouble (M)
43
Toner density sensor trouble (Y)
45
Colour image density sensor trouble
49
LSU thermistor trouble
50
K drum phase sensor trouble
51
CL drum phase sensor trouble
58
Temperature/humidity sensor trouble
(HUD_M/TH_M)
64
Toner supply operation trouble (K)
65
Toner supply operation trouble (C)
66
Toner supply operation trouble (M)
67
Toner supply operation trouble (Y)
70
Improper toner cartridge detection (K)
71
Improper toner cartridge detection (C)
72
Improper toner cartridge detection (M)
73
Improper toner cartridge detection (Y)
74
Toner cartridge CRUM error (K)
75
Toner cartridge CRUM error (C)
F2
76
Toner cartridge CRUM error (M)
77
Toner cartridge CRUM error (Y)
78
Image density registration sensor trouble
91
High density process control high voltage
error (K)
92
High density process control high voltage
error (C)
93
High density process control high voltage
error (M)
94
High density process control high voltage
error (Y)
F3
12
Paper feed tray 1 lift up trouble
22
Paper feed tray 2 lift up trouble
F6
00
ICU-Fax communication trouble (ICU)
01
Fax EEPROM read/write error.
04
Fax modem operation trouble.
21
LIU & Fax soft switch error (combination)
30
Access error to 1-chip on Fax board.
97
Fax Pwb compatibility trouble.
98
Improper Fax & Destination information.
H2
00
Thermistor open trouble (TH_UM_AD2).
01
Lower thermistor open trouble (TH_LM).
02
Thermistor open trouble (TH_US).
03
Thermistor open trouble (TH_UM_AD1)
H3
00
Fuser high temperature trouble (TH_UM).
01
Fuser high temperature trouble (TH_LM).
02
Sub thermistor fusing section high
temperature (TH_US).
H4
00
Fuser low temperature (TH_UM_AD2)
01
Fuser low temperature (TH_LM)
02
Sub thermistor fusing section low
temperature (TH_US)
H5
01
5 continuous (POD1 not reach) jams

Sharp MX-3640N Specifications

General

Print Speed	36 ppm
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	36 ppm
Scan Resolution	600 x 600 dpi
Fax Speed	33.6 kbps
Copy Speed (Black)	36 cpm
Copy Resolution	600 x 600 dpi
Connectivity	USB 2.0, Ethernet
Paper Size	Up to 12" x 18"
Network Connectivity	10/100/1000 Base-T
Operating System Compatibility	Windows, Mac, Linux
Display	7-inch color touchscreen
