Sharp MX-3640N Technical Guide

TROUBLE CODES
SHARP
54
H7
10
Fuser low temperature recovery error
(TH_UM_AD2)
11
Fuser low temperature recovery error
(TH_LM)
L1
00
Scanner feed trouble.
L3
00
Scanner return trouble.
L4
02
Paper feed motor trouble
03
Fusing motor trouble
04
DV motor trouble K
05
DV motor trouble CMY
06
Transfer unit lift trouble
07
Transfer belt motor trouble
11
Shift motor trouble
12
Secondary transfer separation trouble
16
Fusing pressure release trouble
30
Controller fan motor
31
Paper exit cooling fan trouble
32
Power source cooling fan 1 trouble
35
Fusing cooling fan trouble
43
Paper exit cooling fan 2 trouble
50
Process fan trouble
51
Process fan 2 trouble
L6
10
Polygon motor trouble (LSU)
L8
01
No Full wave signal
02
Full wave signal error
20
MFP PWB/LSU mother board
communication trouble
PC
--
Personal counter not installed
U1
01
Battery trouble.
U2
00
MFP EEPROM read/write error
05
Erroneous detection of account
management data
11
MFP PWB EEPROM check sum error.
30
Serial number discrepancy (MFP – PCU)
40
SD card system storage data error
41
HDD system storage data area error
42
Machine adjustment data (system storage
area) error
50
HDD user authentication data sum error
60
Watermark check error.
80
SCU PWB EEPROM read/write error.
81
SCU PWB EEPROM check sum error.
90
PCU PWB EEPROM read/write error.
91
PCU PWB EEPROM check sum error
U6
00
PCU-Desk communication trouble
01
Desk Unit Tray 1 lift motor trouble
02
Desk Unit Tray 2 lift motor trouble
03
Desk Unit Tray 3 lift motor trouble
09
LCC lift motor trouble
10
Desk transport motor trouble
20
LCC communication trouble
21
LCC transport motor trouble
22
LCC 24v power abnormality
50
Desk incompatibility trouble
51
LCC – Main unit combination trouble
52
PCU PWB – Paper feed desk
communication trouble.
U7
50
Communication trouble between main
unit and vendor control
51
Vendor machine error
U9
01
Touch panel trouble
UC
02
CPT - ASIC error
20
DOCC ASIC error

Sharp MX-3640N Specifications

General

Print Speed	36 ppm
Print Resolution	1200 x 1200 dpi
Duplex Printing	Yes
Functions	Print, Copy, Scan, Fax
Print Speed (Color)	36 ppm
Scan Resolution	600 x 600 dpi
Fax Speed	33.6 kbps
Copy Speed (Black)	36 cpm
Copy Resolution	600 x 600 dpi
Connectivity	USB 2.0, Ethernet
Paper Size	Up to 12" x 18"
Network Connectivity	10/100/1000 Base-T
Operating System Compatibility	Windows, Mac, Linux
Display	7-inch color touchscreen
