Sharp MX-4501N - Page 167

MX3500N SIMULATION 7 – 59
<Display item and content description> [MX-4500N/4501N]
OTHER 3/10 VG MD K REVISE(VG) : L *** M *** Drum membrane decrease grid voltage
correction display (KCMY)
0 to 255 0
MD C REVISE(VG) : L *** M ***
MD M REVISE(VG) : L *** M ***
MD Y REVISE(VG) : L *** M ***
4/10 LD MD K REVISE(LD) : L *** M *** Drum membrane decrease laser power
voltage correction (KCMY)
0 to 255 0
MD C REVISE(LD) : L *** M ***
MD M REVISE(LD) : L *** M ***
MD Y REVISE(LD) : L *** M ***
5/10 HV MD K REVISE(HV) : L *** M *** High density membrane decrease
environment GB correction display
(KCMY)
0 to 255 0
MD C REVISE(HV) : L *** M ***
MD M REVISE(HV) : L *** M ***
MD Y REVISE(HV) : L *** M ***
6/10 CP MD K REVISE(CP) : L *** M *** Drum membrane decrease
environment grid voltage correction
display (KCMY)
0 to 255 0
MD C REVISE(CP) : L *** M ***
MD M REVISE(CP) : L *** M ***
MD Y REVISE(CP) : L *** M ***
7/10 DL MD K REVISE COL (DL): L *** M *** Drum membrane decrease discharge
light quantity correction (%)
0 to 100 50
MD C REVISE COL (DL): L *** M ***
MD M REVISE COL (DL): L *** M ***
MD Y REVISE COL (DL): L *** M ***
8/10 DL EV MD K REVISE COL (DL EV): L *** M*** Drum membrane decrease
environment discharge light quantity
correction (%)
–100 to 100 0
MD C REVISE COL (DL EV): L *** M***
MD M REVISE COL (DL EV): L *** M***
MD Y REVISE COL (DL EV): L *** M***
9/10 CRUM Left DESTINATION Machine side control CRUM
destination
Refer to
<CRUM
destination
code list>.
CRUM
information
*2
MODEL TYPE Machine model type 0 to 1 0
Right CRUM DEST_K CRUM destination Refer to
<CRUM
destination
code list>.
CRUM
information
*2
CRUM DEST_C
CRUM DEST_M
CRUM DEST_Y
10/10 CNT Left PROCON COUNT HV Number of execution of high density
process control
0 to 99999999 0
PROCON COUNT HT Number of execution of half tone
process control
0 to 99999999 0
Mode Page number Display item (*: correction value) Content description Display range
Default
value
CPY/PRN
*3
1/2 P
(PROCON)
Left BLACK : GB ***/*** DV ***/*** High density process control GB/DV
data (KCMY)
GB: 230 to 850
DV: 0 to 700
GB: 645
DV: 430
CYAN : GB ***/*** DV ***/***
MAGENTA : GB ***/*** DV ***/***
YELLOW : GB ***/*** DV ***/***
N (M)
(NORMAL
(MIDDLE))
Right BLACK : GB ***/*** DV ***/*** High density normal (middle speed
display) GB/DV data (KCMY)
GB: 230 to 850
DV: 0 to 700
GB: 645
DV: 430
CYAN : GB ***/*** DV ***/***
MAGENTA : GB ***/*** DV ***/***
YELLOW : GB ***/*** DV ***/***
2/2 N (L)
(NORMAL
(LOW))
Left BLACK : GB ***/*** DV ***/*** High density normal (low speed
display) GB/DV data (KCMY)
GB: 230 to 850
DV: 0 to 700
GB: 620
DV: 400
CYAN : GB ***/*** DV ***/***
MAGENTA : GB ***/*** DV ***/***
YELLOW : GB ***/*** DV ***/***
N (H)
(NORMAL
(HIGH))
Right BLACK : GB ***/*** DV ***/*** High density normal (high speed
display) GB/DV data (K)
GB: 230 to 850
DV: 0 to 700
GB: 665
DV: 430
OTHER 1/12 TN/TC Left TN HUD AREA Toner control display humidity area 1 to 14 9
TN HUD DATA Toner control display humidity AD value 0 to 1023 0
TC TMP AREA Transfer display temperature area 1 to 9 4
TC TMP DATA Transfer display temperature AD value 0 to 1023 0
Right TC HUD AREA Transfer display humidity area 1 to 9 4
TC HUD DATA Transfer display humidity AD value 0 to 1023 0
MD HUD AREA Membrane decrease display humidity
area
1 to 14 9
MD HUD DATA Membrane decrease display humidity
AD value
0 to 1023 0
Mode Page number Display item (*: correction value) Content description Display range
Default
value
